.jpg?pp=1&w=800&h=600&product=A6020)
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
100211-4000 100211-4001 100211-4002 100211-4003 100211-4004 110564 12182N 20132111BN 2040111 2323 27060-78301 27060-78301-71 28-1573 40792RI 75917 8EL730126-001 9212259 ALT30320 CAL40111AS DRA3449 EAA-211133 JA792IR
14-033 DXA4158
Specifications
| Amp | 40 A |
| Bottom Mounting Foot Width (B) | 19.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 15 mm |
| Length (L.1) | 150 mm |
| Mount Inside Length or Pad Mount C-C (C) | 67.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 43 mm |
| Outside Diameter (O.D.2) | 76 mm |
| Plug Code | PL_2500 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 48 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KOMATSU | Various Models | [Nippondenso equipped] | |
| KOMATSU | Various Models | [Nippondensoequipped] | |
| TOYOTA | 5FD10 | [2J] | 01.1986- |
| TOYOTA | 5FD10 | [2JT] | 01.1986- |
| TOYOTA | 5FD14 | [2J] | 01.1988-12.1994 |
| TOYOTA | 5FD15 | [2J] | 01.1986-12.1995 |
| TOYOTA | 5FD15 | [2JT] | 01.1986-12.1995 |
| TOYOTA | 5FD18 | [2J] | 01.1986-12.1995 |
| TOYOTA | 5FD18 | [2JT] | 01.1986-12.1995 |
| TOYOTA | 5FD20 | [1Z] | 01.1986-12.1988 |
| TOYOTA | 5FD20 | [2J] | 01.1986-12.1994 |
| TOYOTA | 5FD23 | [1Z] | 01.1986-12.1988 |
| TOYOTA | 5FD23 | [2J] | 01.1986- |
| TOYOTA | 5FD23 | [2JT] | 01.1986- |
| TOYOTA | 5FD25 | [1Z] | 01.1986-12.1988 |
| TOYOTA | 5GD33 | [3F] | 01.1988- |
| TOYOTA | 5GD35 | [3F] | 01.1988- |
| TOYOTA | 5GD38 | [3F] | 01.1988- |
| TOYOTA | 5GD40 | [3F] | 01.1988- |
| TOYOTA | 5GD45 | [3F] | 01.1988- |
| TOYOTA | FORKLIFT |
Reference Information
9212259 2040111 110564 40792RI 31400M80030 ALT30320 20132111BN EAA-211133 100211-4004 445841 12182N 100211-4000 2323 100211-4001 100211-4002 ALT6049 3049393 100211-4003 DRA3449 A12DE0723A2 ALT421110 75917 CGB-13449 8EL730126-001 ALTW142 27060-78301-71 CAL40111AS 27060-78301 5540850 JA792IR 28-1573Video/Publications
100211-4000 100211-4001 100211-4002 100211-4003 100211-4004 110564 12182N 20132111BN 2040111 2323 27060-78301 27060-78301-71 28-1573 40792RI 75917 8EL730126-001 9212259 ALT30320 ALT421110 ALTW142 CAL40111AS CGB-13449 DRA3449 EAA-211133 JA792IRAdd Your Number
