- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
UD20572S AS-PL CST20273GS CASCO S-80304 DIXIE S114-927 HITACHIList STH4927 KRAUF 255224 KUHNER 23300JK20A NISSAN 160.595.122 PSH 6020273.1 SANDO 19067R WAI / TRANSPO 91-25-1203 WILSON 160595122 19067 Lester Nissan 91251203 Wilson S114927 Hitachi TRS115 TWA snj439 23300JK20B 23300JK20D S114927A S114927SEL +line HXS094 255423 Elstock showSpecifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 95 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 68 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| INFINITI | 370Z 3.7 | 01.2012-12.2015 | |
| INFINITI | EX35 3.5 | 01.2008-12.2012 | |
| INFINITI | EX37 3.7 | 01.2013-12.2013 | |
| INFINITI | FX35 3.5 | 01.2009-12.2012 | |
| INFINITI | FX37 3.7 | 01.2013-12.2013 | |
| INFINITI | G25 2.5 | 01.2012-12.2012 | |
| INFINITI | G35 3.5 | 01.2007-12.2008 | |
| INFINITI | G37 3.7 | 01.2012-12.2014 | |
| INFINITI | M35 3.5 | 01.2009-12.2010 | |
| INFINITI | M37 3.7 | 01.2012-12.2013 | |
| INFINITI | Q40 3.7 | 01.2014-12.2014 | |
| INFINITI | Q50 3.7 | 01.2014-12.2015 | |
| INFINITI | Q60 3.7 | 01.2014-12.2015 | |
| INFINITI | Q70 3.7 | 01.2014-12.2015 | |
| INFINITI | QX50 3.7 | 01.2014-12.2015 | |
| INFINITI | QX70 3.7 | 01.2014-12.2015 |
Reference Information
S114927C S114927B S114927A 160.595.122.415 UD20572S 2330MJK20BRW 160.595.122 23300JK20D 23300JK20C 23300JK20B 23300JK20A S114-927 23300JK20ABR 255224 91-25-1203 160.595.122.080 S2101S STH4927 6020273.1 STR3174 CST20273GS 19067R S-80304Video/Publications
160.595.122 19067R 23300JK20A 255224 6020273.1 91-25-1203 CST20273GS S-80304 S114-927 STH4927 UD20572S 160.595.122.080 160.595.122.415Add Your Number
