Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 190 mm |
| Mount Hole Center - Center (O.1) | 109 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 17.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KUBOTA | Engine | [D850] | 01.1987- |
Reference Information
16611-63013 16611-63012 19090-17861 228000-0150 228000-3661 228000-3660 220596 228000-0990 228000-0991 16611-63011 16611-63010 DSN2152 CST40194AS 5040175 JS908 228000-1530 228000-1531 STR6077 20432491BN STR70073 228000-7670 20513076 20908L 19090-17862 128000-0050 20432491OE 77700-06123 17098N 228000-0971 MAV421940 STRS192 128000-9051 228080-3661 128000-9050 690.549.092.260 8080236 20908 18019N 22.0908 111021 1623563010 1623563011 CST40194GS 22.0908M 8EA732851-001 8001 AET0908 16695-63011 19269-63011 19269-63010 STR6811 8212471 RNL228000-1531 16695-63013 19269-63013 19269-63012 19269-19010 UD819296(DENSO)S 690.549.092.050 EAA-111092 6040194.1 690.549.092.059 19090-15741 20513059 690.549.092.058 6040194 33824 690.549.092.415 PRSS192Add Your Number
