Specifications
Kilowatt | 1 kW |
Length (L.1) | 212 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | M12x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 33 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | City 1.4 i-VTEC | [L13Z1] | 09.2008- |
HONDA | Civic 1.4 | [L13Z1] | 10.2008- |
HONDA | Jazz 1.2 | [L12B1] | 07.2008- |
HONDA | Jazz 1.3 | [L13Z1] | 07.2008- |
HONDA | Jazz 1.3 | [L13Z2] | 07.2008- |
HONDA | Jazz 1.4 | [L13Z1] | 11.2008- |
Reference Information
458943 31200-R3R-E01 CGB-54441 255315R 31200-PWA-901 6040417 120.577.092.059 DENDSN1385 120.577.092.058 CST40417GS MAV424170A 220998A DSN1385 3359 336596 120.577.092.050 116256 91-29-5794 246-08103 LRS2768 428080-5410 428000-4090 DSKEW 120.577.092.261 STN3102 19013N 31200-RB1-003 CGB-20673 25-4441 J5214060 88214662 20432714OE S-80495 CST40417AS 20432714BN RAS31784 428000-3390 AEY2768 91-29-5794N 255315 428000-5410 31200-RB1-013 DSKEF DRS0673 UD808816(DENSO)S 17998N STR6731 6040417.1 WOOSTR70418 MAV424170 LRS02768Add Your Number
