Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 32 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ERKUNT | 502e 3.3 | [1103D-33TA] | |
ERKUNT | 504e 3.3 | [1103D-33TA] | |
ERKUNT | 652e 3.3 | [1103D-33TA] | |
ERKUNT | 652 Lux 3.3 | [1103D-33TA] | |
ERKUNT | 654e 3.3 | [1103D-33TA] | |
ERKUNT | 654 Lux 3.3 | [1103D-33TA] | |
ERKUNT | 702e 3.3 | [1103D-33TA] | |
ERKUNT | 702 Lux 3.3 | [1103D-33TA] | |
ERKUNT | 704 Lux 3.3 | [1103D-33TA] | |
ERKUNT | 804.3 Lux 3.3 | [1103D-33TA] | |
LINDNER | 103 4.4 | [1104C-44] | |
LINDNER | 64 3.3 | [1103D-33TA] | |
LINDNER | 74 3.3 | [1103D-33TA] | |
LINDNER | 83 4.4 | [1104C-44] | |
LINDNER | 93 4.4 | [1104C-44] | |
MCCORMICK | F120 F 4.4 | [1104D-44T] | |
MCCORMICK | F120 GE 4.4 | [1104D-44T] | |
MCCORMICK | F120 XL 4.4 | [1104D-44T] | |
PERKINS | Engine | [1103D] | |
PERKINS | Engine | [1104D] | |
URSUS | 5044 | [1103D] | 01.2014- |
Reference Information
UD30100S 3125018 20419531BN STR60720 72735925 AZE4165 MAHMS297 MS297 20419531OE LETIS1208 11.131.716 332053 2873K627 331044 254994M CST21135GS 6525845M91 BOM 107264 UNIT 4213912M91 CST21135AS 3218978 IS1208 6021135 WG2045055 2873K633 182-109 182-30393 700.536.103.090 254994 700.536.103.312 6021135.1 SIS135 STI8513 700.536.103.310Add Your Number
