Associated Numbers
FS10E10 S3078Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 14.5 mm |
Inside Diameter (I.D.1) | 25 mm |
L.B+ | 24 mm |
Length (L.1) | 67 mm |
Outside Diameter (O.D.1) | 54 mm |
Outside Diameter (O.D.2) | 47.7 mm |
Type | Solenoid |
Unit Type | VALEO |
Voltage | 12 V |
Reference Information
595583 UD00040SS 501790 SSV2792Video/Publications
FS10E3 UD00040SS 446507 458392 FS10B3 FS10E10 S3078 438228Add Your Number
