- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
1012115260Associated Numbers
AEB1534 AUTOELECTRO
112356 CARGO
CAL40217AS CASCO
DRA3517 DELCO
1012115260 DENSO List
1012115261 DENSO List
1012115330 DENSO List
1022111360 DENSO List
EAA222110 EAA
57276 EAI
282750 ELSTOCK
JA1534IR HC PARTS
8EL737837001 HELLA
11.1534 LAUBER
LRA01598 LUCAS
9212887 POWERMAX
195.546.100 PSH
2706017170 TOYOTA List
2706017171 TOYOTA
2706017220 TOYOTA
13497N WAI / TRANSPO
ALT30089 WOODAUTO
Denso 1012115260, 1012115261
Lester 22598
Toyota 2706017170, 2706017171
0986083720
1012115260
1012115261
1022111360
1022111361
1022111362
112356
195942080
2706017170
2706017171
2706017220
282750
ALTH096
CAL40217AS
DAN1114
F042A0H096
F042A0H096HNC
HJA1534IR
JA1534IR
LRA01598
TRA203
658350 dxa433U dxa8110
Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 57.50 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.50 mm |
Length (L.1) | 173 mm |
OEM Product | No |
Plug Code | PL_3314 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 2 qty |
Pulley Groove Width (W.1) | 12 mm |
Pulley Outside Diameter (O.D.1) | 48 mm |
Pulley Outside Diameter (O.D.2) | 76 mm |
Pulley to Mount Distance (A) | 92 mm |
Pulley Type | Solid |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Land Cruiser 4.2 Diesel | [1H-Z] | 01.1990-12.1997 |
TOYOTA | Land Cruiser 4.2 TD | [1HD-FT] | 03.1995-12.1997 |
TOYOTA | Land Cruiser 4.2 TD | [1HD-FTE] | 01.1998- |
TOYOTA | Land Cruiser 4.2 TD | [1HD-T] | 01.1990-12.1997 |
Reference Information
002-T538 | ASHIKA |
002-T594 | ASHIKA |
101211-5260 | DENSO |
101211-5261 | DENSO |
101211-5330 | DENSO |
102211-1360 | DENSO |
11.1534 | LAUBER |
112356 | CARGO |
13497N | WAI / TRANSPO |
195.546.100 | PSH |
195.546.100.415 | PSH |
195.942.080.050 | PSH |
20132712BN | REAL |
20132712OE | REAL |
2040217 | SANDO |
2706017150 | TOYOTA |
27060-17170 | TOYOTA |
27060-17171 | TOYOTA |
27060-17220 | TOYOTA |
28-2750 | ELSTOCK |
2T538 | JAPKO |
2T594 | JAPKO |
401534RI | KUHNER |
447038 | LOGISTIK |
57276 | EAI |
8EL737-837-001 | HELLA |
9212887 | POWERMAX |
A12DE0375 | SIDAT |
A12DE0375A2 | SIDAT |
A6104 | AS-PL |
AEB1534 | AUTOELECTRO |
ALT30089 | WOODAUTO |
ALT422170 | SIOM |
ALT538 | JAPANPARTS |
ALT594 | JAPANPARTS |
ALT6075 | ELECTROLOG |
ALT6781 | ELECTROLOG |
ALTW208 | 3EFFE |
ANM35737X | ANDEL |
CAL40217AS | CASCO |
CAL40217GS | CASCO |
DRA3517 | DELCO |
F032112356 | CARGO |
JA1534IR | HC PARTS |
LRA01598 | LUCAS |
LRA1598 | LUCAS |
STX101532 | STARDAX |
