Associated Numbers
A6175 ASPL List
UD01430A ASPL
AEK3123 AUTOELECTRO
116056 CARGO
CAL40255 CASCO
DRA0254 DELCO
1042103720 DENSO List
EAA222138 EAA
285735 ELSTOCK
4R8310300AB FORD List
AG1241 GHIBAUDI
C2C20533 JAGUAR
LRA03123 LUCAS
LRA3123 LUCAS
89215552 POWERMAX
195.936.100 PSH
845.505.150 PSH
24123 WAI / TRANSPO
24123R WAI / TRANSPO
ALT30376 WOODAUTO
02C2C20533
1042103720
116056
285735
2905457
4R8310300AB
845505150
930254
C2C20533
DRA0254
LRA03123
TNA082
Specifications
Amp | 150 A |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 12 mm |
Diameter (D.3) | 14.5 mm |
Grooves | 6 qty |
Length (L.1) | 180.5 mm |
Mount Inside Length or Pad Mount C-C (C) | 47 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 57 mm |
Pad mount thickness (E.1) | 40 mm |
Pad mount thickness (E.2) | 50 mm |
Pad mount thickness (E.3) | 50 mm |
Plug Code | PL_3321 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 23 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JAGUAR | S-Type 2.7 D V6 | [AJD] | 06.2004-10.2007 |
JAGUAR | XJ6 2.7 TD V6 | [AJD] | 10.2005-03.2009 |
Reference Information
845.505.150 447175 2040255 LRA03123 C2C20533 CAL40255RS 116056 5540888 ANM32474X 89215552 ALT231060 CAL40255AS 195.936.100 24123R 24123 LRA3123 AEK3123 104210-3720 ALT131070 DRA0254 CAL40255GS 553399RI AG1241 ALT30376 CAL40255ES CAL40255 RNL104210-3720 02C2C20533 28-5735 4R8310300AB CAL40255OS 20132552BN EAA-222138 A12DE1112A2 A6175 ALT6794 UD01430AVideo/Publications
104210-3720 116056 195.936.100 20132552BN 2040255 24123 24123R 28-5735 4R8310300AB 553399RI 845.505.150 89215552 A6175 AEK3123 AG1241 ALT131070 ALT231060 ALT30376 C2C20533 CAL40255 CAL40255AS CAL40255ES CAL40255GS CAL40255OS CAL40255RS DRA0254 EAA-222138 LRA03123 LRA3123 RNL104210-3720 UD01430AAdd Your Number
