- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
104210-3920Associated Numbers
UD11490A ASPL
113975 CARGO
2261 CEVAM
1042103920 DENSO List
1042103921 DENSO List
287522 ELSTOCK
RE186320 JOHN DEERE List
RE257541 JOHN DEERE List
LRA03912 LUCAS
635.511.150 PSH
12660R WAI / TRANSPO
DXA4077 ANJ285GQ 658502
1042103920
635511150
LRA03912
RE186320
RE257541
TRA345
J&N 40052264
Arrowhead AND0548
Denso 021080014, 0210800140, 1042103920, 1042103921
John Deere RE186320, RE257541
Lester 12660
PIC Picture ID 2905216
Wilson 90295815
021080014, 104210392, 1042103920, 1042103921
Substitutes:
JANNCO 40052264R
References:
J&N 40052264
JANNCO 40052264R
Arrowhead ND1042103921
Denso 021080014, 1042103921
Wilson 90295815
AND0548
Denso 1042103920
John Deere RE186320, RE257541
Lester 12660
PIC Picture ID 2905216
Specifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 58 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Length (L.1) | 167 mm |
OEM Product | No |
Plug Code | PL_3314 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 8 qty |
Pulley Outside Diameter (O.D.1) | 64 mm |
Pulley to Mount Distance (A) | 91 mm |
Pulley Type | Solid |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 7720 6.8 | [4V-CR] | 01.2003-12.2006 |
JOHN DEERE | 7820 6.8 | [4V-CR] | 01.2003-12.2006 |
JOHN DEERE | 7920 8.1 | [JD6081T] | 01.2003-12.2006 |
JOHN DEERE | 9120 8.1 | [6081H] | 01.2001-12.2007 |
JOHN DEERE | 9220 12.5 | [6125H] | 01.2001-12.2007 |
JOHN DEERE | 9320 12.5 | [6125H] | 01.2001-12.2007 |
JOHN DEERE | 9420 12.5 | [6125H] | 01.2001-12.2007 |
JOHN DEERE | 9520 12.5 | [6125H] | 01.2001-12.2007 |
Reference Information
104210-3920 | DENSO |
104210-3921 | DENSO |
113975 | CARGO |
12660R | WAI / TRANSPO |
20132565BN | REAL |
2040565.0 | SANDO |
2261 | CEVAM |
28-7522 | ELSTOCK |
447043 | LOGISTIK |
553989RI | KUHNER |
635.511.150 | PSH |
635.511.150.058 | PSH |
635.511.150.415 | PSH |
A6290 | AS-PL |
CAL40565AS | CASCO |
F032113975 | CARGO |
LRA03912 | LUCAS |
LRA3912 | LUCAS |
RE186320 | JOHN DEERE |
RE257541 | JOHN DEERE |
SE501837 | JOHN DEERE |
STX110140 | STARDAX |
UD11490A | AS-PL |
Video/Publications
A6290Related Items
