Information
104210-3500Associated Numbers
ANJ227 658509 UD11483A ASPL 12635 DELCO 12638 94780 1042103500 DENSO 1042104480 DENSO  1042104481 A80291 DIXIE 06311RCB505RM HONDA 31100RCB505RM 31100RCBY01 HONDA  31100RCBY02 31100RCBYA02 CSC50   CSD48 11030R WAI / TRANSPO 90295581 WILSON ALT30462 WOODAUTO A11030 DXA4014 DXA576 11030 11030N 125555130 TNA091 JANNCO 40052368R Wilson References: Arrowhead AND0401 Denso Honda Lester Remy Light Duty J N 40052368 VND0401 Beck Arnley 1861180 Bosch AL4057X PIC Picture ID 2905187 06311-RCB-505RM 104210-3500 104210-4480 104210-4481 20132523BN 2040325 31100-RCB-505RM 31100-RCB-Y01 31100-RCB-Y02 31100-RCB-YA02 553606RI 90-29-5581 A-80291 CAL40325AS anj227 CASCO List REAL dxa4014 Plug + div PSH Suzuki TWA CAS GM 88861823 KRAUF ALN0202AN ALN0202GB ALN0202UX Motorherz ALN0202WA 1297401ND3 WPS 2905187A dxa576
TG1042104480 TG1042104481
Specifications
| Amp | 130 A |
| Bottom Mounting Foot Width (B) | 47 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 10 mm |
| Length (L.1) | 157 mm |
| OEM Product | No |
| Plug Code | PL_4001 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 65 mm |
| Pulley to Mount Distance (A) | 86 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Accord 3.0 | 01.2004-12.2007 |
Reference Information
| 06311-RCB-505RM | HONDA |
| 104210-3500 | DENSO |
| 104210-4480 | DENSO |
| 104210-4481 | DENSO |
| 11030 | WAI / TRANSPO |
| 11030N | WAI / TRANSPO |
| 11030R | WAI / TRANSPO |
| 12635 | DELCO |
| 12638 | DELCO |
| 20132523BN | REAL |
| 2040325 | SANDO |
| 31100-RCB-505RM | HONDA |
| 31100-RCB-Y01 | HONDA |
| 31100-RCB-Y02 | HONDA |
| 31100-RCB-YA02 | HONDA |
| 553606RI | KUHNER |
| 90-29-5581 | WILSON |
| 94780 | DELCO |
| A-80291 | DIXIE |
| ALT30462 | WOODAUTO |
| ALT6237 | ELECTROLOG |
| CAL40325AS | CASCO |
| CSC50 | HONDA |
| CSD48 | HONDA |
| UD11483A | AS-PL |
Video/Publications
A6329Related Items
