Associated Numbers
AEK3199AUTOELECTRO
96540542CHEVROLET List
96838439CHEVROLET
96954113CHEVROLET
EAA221848EAA
286631ELSTOCK
LRA03521LUCAS
1019046RSRS
8483NWAI / TRANSPO
ALT40183WOODAUTO
16201206
235505085
8483
96540542
96954113
ALTH216
DRA0302
F042A0E000
F042A0H216
F042A0H216FEB
TRA104
235510085
96838439
KJ7C19A
LRA03521
TRA109
40012215
Delco 96540542, 96838439, 96954113
Lester 8483
PIC Picture ID 2406240
ADR0337
General Motors 96540542, 96838439
Lester 8483
PIC Picture ID 2406240
Wilson 90014526
40012215
VXA007 656214 65-6214
Specifications
Amp | 85 A |
Bottom Mounting Foot Width (B) | 12.5 mm |
Diameter (D.1) | 9.5 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | 8.5 mm |
Grooves | 6 qty |
Length (L.1) | 184 mm |
Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Plug Code | PL_4305 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 36 mm |
Pulley Type | SOLID |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Lacetti 1.4 | [F14D3] | 01.2005- |
CHEVROLET | Lacetti 1.6 | [F16D3] | 01.2005- |
CHEVROLET | Nubira 1.6 | [F16D3] | 01.2005- |
DAEWOO | Nubira 1.8 | [F18D3] | 01.2005- |
Reference Information
AEK3199 LRA03521 ALT2324 ALT2049 96838439 CAL46107GS ALT40183 8483N 20160701OE ALTL525 CAL46107AS 5560131 28-6631 96954113 96540542 ALT481070 446056 EAA-221848 A12VA0812 20160701BN A12VA0812A2 LRA3521 2046107 2046107.1 A9046 96989020 A9240Video/Publications
28-6631 8483N 96540542 96838439 96954113 A9240 AEK3199 ALT40183 ALT481070 ALTL525 EAA-221848 LRA03521 LRA3521Add Your Number
