Associated Numbers
Arrowhead SHI0128
Hitachi S114828A, S114828B, S114828C
Lester 18347
Mercury Marine 50804312T1
PIC Picture ID 104365
Yamaha 67F8180000, 67F8180001, 67F8180002
Wilson 712518347
Arrowhead SHI0128
J&N 41044071
Hitachi S114828A
Mercury Marine 50804312T1
Yamaha 67F8180000, 67F8180001, 67F8180002
Wilson 712518347
S114828A, S114828B, S114828C
References:
Hitachi S114828C
18347 Lester
18347N WAI
18347R WAI
22451HI2 WAI
50804312T1 Mercury Marine
67F8180000 Yamaha
67F8180001 Yamaha
67F8180002 Yamaha
970506132 PSH
S114828 Hitachi
S114828B Hitachi
709316
Specifications
Kilowatt | 1.4 kW |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
No./Mount holes | 2 qty |
No./Teeth | 13 qty |
Pinion/Drive OD | 39.9 mm |
Rotation | CW |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MARINER | 75ELHPT | 84cu in, 84CI 4-Stroke | 2000, 2001 |
MARINER | 75ELHPT 4-Stroke | 84.6ci - 75 H | 2000, 2001 |
MARINER | 75ELPT | 84cu in, 84CI 4-Stroke | 2000, 2001 |
MARINER | 75ELPT 4-Stroke | 84.6ci - 75 H | 2000, 2001 |
MARINER | 90ELHPT | 1600cc, 1.6L/97CI 4-Stroke | 2000, 2001 |
MARINER | 90ELHPT 4-Stroke | 1.6L - 97.4ci - 90 H | 2000, 2001 |
MARINER | 90ELPT | 1600cc, 1.6L/97CI 4-Stroke | 2000, 2001 |
MARINER | 90ELPT 4-Stroke | 1.6L - 97.4ci - 90 H | 2000, 2001 |
MARINER | 90ELPT Coastal | 1600cc, 1.6L/97CI 4-Stroke | 2000 |
MARINER | 90ELPT Coastal 4-Stroke | 1.6L - 97.4ci - 90 H | 2000 |
MARINER | 90EXLPT Saltwater | 1600cc, 1.6L/97CI 4-Stroke | 2001 |
MARINER | 90EXLPT Saltwater 4-Stroke | 1.6L - 97.4ci - 90 H | 2001 |
MERCURY MARINE | 75ELHPT | 84cu in, 75HP 84.6CI 4-Stroke | 2000, 2001 |
MERCURY MARINE | 75ELHPT | 84cu in, 84CI 4-Stroke | 2000, 2001 |
MERCURY MARINE | 75ELHPT 4-Stroke | 75H | 2000, 2001 |
MERCURY MARINE | 75ELPT | 84cu in, 75HP 84.6CI 4-Stroke | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 75ELPT | 84cu in, 84CI 4-Stroke | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 75ELPT 4-Stroke | 75H | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90ELHPT | 1600cc, 1.6L/97CI 4-Stroke | 2000, 2001 |
MERCURY MARINE | 90ELHPT | 97cu in, 90HP 97.4CI 4-Stroke | 2000, 2001 |
MERCURY MARINE | 90ELHPT 4-Stroke | 90H | 2000, 2001 |
MERCURY MARINE | 90ELPT | 1600cc, 1.6L/97CI 4-Stroke | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90ELPT | 1600cc, 90HP 1.6L/97.4CI 4-Stroke | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90ELPT 4-Stroke | 90H | 2000, 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90ELPT Saltwater | 1600cc, 1.6L/97CI 4-Stroke | 2004, 2005 |
MERCURY MARINE | 90ELPT Saltwater | 1600cc, 90HP 1.6L/97.4CI 4-Stroke | 2004, 2005 |
MERCURY MARINE | 90ELPT Saltwater 4-Stroke | 90H | 2004, 2005 |
MERCURY MARINE | 90EXLPT Saltwater | 1600cc, 1.6L/97CI 4-Stroke | 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90EXLPT Saltwater | 1600cc, 90HP 1.6L/97.4CI 4-Stroke | 2001, 2002, 2003, 2004, 2005 |
MERCURY MARINE | 90EXLPT Saltwater 4-Stroke | 90H | 2001, 2002, 2003, 2004, 2005 |
YAMAHA | F100TLR | 100H | 2001, 2002, 2003 |
YAMAHA | F100TLR | 1999, 2000, 2001, 2002 | |
YAMAHA | F100TXR | 100H | 2001, 2002, 2003 |
YAMAHA | F100TXR | 1999, 2000, 2001, 2002 | |
YAMAHA | F75TLR | 75H | 2003, 2004 |
YAMAHA | F75TLR | 2003, 2004 | |
YAMAHA | F80TJR | 80H | 2002, 2003 |
YAMAHA | F80TJR | 2001, 2002 | |
YAMAHA | F80TLR | 80H | 2001, 2002, 2003 |
YAMAHA | F80TLR | 1999, 2000, 2001, 2002 | |
YAMAHA | F80TXR | 80H | 2000 |
YAMAHA | F90TJR | 90H | 2003, 2004 |
YAMAHA | F90TJR | 2003, 2004 | |
YAMAHA | F90TLR | 90H | 2003, 2004 |
YAMAHA | F90TLR | 2003, 2004 |
