Associated Numbers
0001230007 0001230010 0001230023 0986018980 113182 18374N 20401351BN 20401351OE 25-3059 254521 254521B 254521I 500325145 500338952 504059251 6010153 8039 AEY1562 CST10153AS CST10153GS EAA-121273 LRS01562 S0081 S5014L STR22029 AUTOELECTRO BOSCHList BOSCH CARGO CASCO CEVAM EAA121273 EAA 253059 ELSTOCK IVECO IVECOList LUCAS PRESTOLITE REAL SANDO WAI / TRANSPO WOODAUTO Arrowhead SBO0136 JANNCO 41024066R Bosch 9007044015 SR9979N SR9979X Case Ford Iveco 47551009 Lester 18374 PIC Picture ID 1206047 Wilson 91157194 0001367028 Substitutes: J N 41024066 MAHLE MS79 References: BSR9979X J& 0986017987 Magneti Marelli MSN2039 11.131.604 AZF4155 IS1262 41029036 SIA0012 701773 bxs9002 bxs9013 snb146 0001262008 ruil 0986018981 11018980 EuroTec 11130133 Mahle 11131604 11132156 Cargo 18374R Elstock 5801441814 590530093 PSH 8818980F Friesen 918980 EDR AZE4241 DRS8980 Remy F042002158 F042S02158 IS1386 Lucas MS207 SM2824 Honda STR1231sa Electrolog STR2302 Unipoint 500536093 69bx230007Specifications
Kilowatt | 3 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 104 mm |
Mount Hole Center - Center (O.2) | 146 mm |
Mount Hole Center - Center (O.3) | 104 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NEW HOLLAND | L-60 | 01.1996-12.1999 | |
NEW HOLLAND | L-65 | 01.1996-12.1999 | |
NEW HOLLAND | L-75 | 01.1996-12.1999 | |
NEW HOLLAND | L-85 | 01.1996-12.1999 | |
NEW HOLLAND | L-95 | 01.1996-12.1999 | |
NEW HOLLAND | LM640 Telescopic Loader | ||
NEW HOLLAND | TL80A | 01.1997- |
Alternatives >>>
S0116 - Larger bodied starter
S9055 - Magneton OSGR style
Reference Information
254521B LRS1562 S12BH0857A2 87470949 EAA-121273 8039 CST10153GS 5801441814 220550 RNL1898 590.530.093.011 590.530.093.012 500338952 CST10153AS 0001230007 6010153 20401351OE STR22029 LRS01562 254521 47783079 0001230023 1230010 500325145 20401351BN 113182 CGB-28980 S0081 AEY1562 504059251 STR1927 MAV121530 590.530.093.280 STRL092 18374N 1230007 25-3059 986018980 254521I S5014L 0001230010 1230023 000986018980Video/Publications
0001230007 0001230010 0001230023 0986018980 113182 18374N 20401351BN 20401351OE 25-3059 254521 254521B 254521I 500325145 500338952 504059251 6010153 8039 AEY1562 CGB-28980 CST10153AS CST10153GS EAA-121273 LRS01562 LRS1562 MAV121530 RNL1898 S0081 S5014L STR22029 STRL092 220550Add Your Number
