Associated Numbers
0001241008 0001241012 0001261016 0001261022 114327 254213 S0255 STR50295 UD12677S
S0255 ASPLList
UD12677S ASPL
0001241008 BOSCHList
0001241012 BOSCHList
0001261016 BOSCHList
0001261022 BOSCHList
114327 CARGO
STR50295 WOODAUTO
0001241008 BOSCHList
0001241012 BOSCHList
0001261016 BOSCHList
114327 CARGO
CST10803AS CASCO
EAA121694 EAA
20401308BN REAL
6010803 SANDO
30153N WAI / TRANSPO
STR50295 WOODAUTO
J&N 41024130
Bosch 0001261016
References:
Arrowhead SBO0294
J&N 41024130
Bosch 0001261016
&N 41024141
Bosch 0001241008
References:
Arrowhead SBO0286
J&N 41024141
Bosch 0001241008
Lester 30153
PIC Picture ID 120663
0001241008 Bosch
0001241012 Bosch
0001261016 Bosch
11090171 EuroTec
120663 PIC
30153 Lester
30153N WAI
551520113 PSH
A90930 ATL
D612600090293 Ford
F042S02136 Bosch
F042S02154 Bosch
STR1260sa Electrolog
STR2412 Unipoint
STR2462 Unipoint
WD61509QD
S0086
Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 326 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HOWO | WD615 | ||
SCANIA | WD615 | ||
WEICHAI | WD615 |
Reference Information
1261032 6010803 6.126E+11 0001241008 0001261032 1261016 114327 1241008 UD12677S 0001261016 8090 STRF161 STR50295 S0255 0001261022 612600090293J 1241012 PRSF161 STR10336 1261022 20401308BN 0001241012 254213 551.520.113.210 551.520.113.010 STR1260 CST10803AS CGB-23126Video/Publications
0001241008 0001241012 0001261016 0001261022 114327 254213 S0255 STR50295 STRF161 UD12677SAdd Your Number
