S0270 - Brand new AS-PL Starter motor

Brand new AS-PL Starter motor
Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 262.51 including GST

NZ$ 228.27 excluding GST


or four payments of $65.63 with
Afterpay Payment Offer Learn More

UOM:
each
Alternative Item:
SGB-C9001
Product Code:
S0270
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Purchase Qty:

0001125609
0001125609 0001125610 059911024E 059911024EX 059911024H 059911024HX 114775 115502 12280 17678N 20401124BN 20401124OE 25-4297 254373 254373B 260-22108 300.586.093 3384 42024050 6010421 88213966 91-15-7318 95560410800 955604108X AEY2330 BOS0001125609 CST10421 CST10421AS CST10421ES CST10421GS CST10421OS CST10421RS EAA-121405 LRS02624 S-6306 S0270 SG0579 STR50540 ASPLList AUTOELECTRO BOSCHList CARGO CASCO CEVAM 26022108 DIXIE S6306 EAA121405 EAA EAI 254297 ELSTOCK GHIBAUDI HERTH+BUSS LUCAS POWERMAX PSH REAL SANDO VW WAI / TRANSPO 91157318 WILSON WOODAUTO Bosch Remy Light Duty 16244 Wilson References: Arrowhead SBO0295 0986024050 2405 SR0793X Lester 17678 Lucas LRS2624 PIC Picture ID 1206396 Porsche Volkswagen 056911024J 059911023J 059911024CX 059911024J 059944024E Youtech/PartRef 423808 Substitutes: J N 41024329 J& ruil 11024050 EuroTec 300586093 910244 EDR A24050 ATL DRS0244 STR1585sa Electrolog S0213 0001125519 0001125520 0001125521 BOSCH 114690 CST10368 CST10368AS CST10368GS 3066 DRS0566 DELCO EAA121104 254002 220683 ERA SG0595 CS1521 HC PARTS STB4519 KRAUF STB4519BA 22.3082M LAUBER LRS02330 943215211010 MAGNETI MARELLI 200.536.093 300.577.093 20401863BN 20401863OE 6010368 458538 VALEO 059911023S 059911023SX 059911024C 059911024JX UNIT BOM 1205035 BOS0001125519 STR50544 EAA121157 EAA122022 11090174 11090187 Cargo 12103 Elstock 300577093 33330 33330R 910566 A79140 Casco OSM11850 Optimum STR1751SA STR2291 Unipoint bxs0179 701058 7010584 0001109054 0001125609SEL +line 021262 Da Silva Exchange 10439518 Alanko 106949 FARC 12130267 AES 1986S00824 223036 Lauber DAS Dixie 311282092 DRI 332111 Logistik 439518 458920 Valeo 48213966 MD Rebuilt Sando Power Max 88214280 AEX1061 Auto Electro AS1898AC Charge ASM1629 Apec BOS0001125521 Wood Airframe IR8593 Protech KTR601172186 KTR NSM1629 Napa (UK) RNL2405 RNL AS-PL S0270PR S132068 Short code S144840 S148699 S6396 SBE1367 Everkraft SBO1231 Quasar SEG0001125609 WOOSTR50540 0-001-125-609 0-001-125-610 J&N ELECTRICAL PRODUCTS 410-24329 LESTER ELECTRIC PORSCHE 955-604-108-00 955-604-108X 955-604-108-X VOLKSWAGEN 056-911-024J 059-911-023J 059-911-024CX 059-911-024E 059-911-024EX 059-911-024H 059-911-024HX 059-911-024J 059-944-024E Reman Service Europe 0-986-024-050 0-986-024-057 Electric Ltd New IAT S17678 Industry (Europe) MPA 120-6396 PPR BOS051 Romaine SEG Automotive 0001.125.609 Standard Starter Drive Group Voltux V1-17678
Kilowatt2.20 kW
Length (L.1)235 mm
Mount Hole Center - Center (O.1)100.00 mm
Mount Hole Center - Center (O.2)23.00 mm
Mount Hole Center - Center (O.3)104.00 mm
Mount Hole Diameter (C.1)10.50 mm
Mount Hole Diameter (C.2)10.50 mm
Mount Hole Diameter (C.3)M10x1.5 mm
No./Mount holes3 qty
No./Mount holes with thread1 qty
No./Teeth9 qty
No./Teeth (Replaces)9 qty
OEM ProductNo
Pinion at Rest (B)25 mm
Product LineStandard Line
Product TypeBrand new
RotationCW
Spigot Diameter (A)76 mm
Unit TypeBOSCH
Voltage12 V
Make Model Type Year
AUDI A5 3.0 Quattro Sportback [CAKA] 01.2010-01.2017
AUDI A5 3.0 Quattro Sportback [CGWC] 01.2010-01.2017
AUDI A5 3.0 Quattro Sportback [CREC] 01.2010-01.2017
AUDI A5 3.0 Quattro Sportback [CTDA] 01.2010-01.2017
AUDI A5 Sportback (8TA) S5 quattro CAKA 01.2010-01.2017
AUDI A5 Sportback (8TA) S5 quattro CGWC 01.2010-01.2017
AUDI A5 Sportback (8TA) S5 quattro CREC 01.2010-01.2017
AUDI A5 Sportback (8TA) S5 quattro CTDA 01.2010-01.2017
AUDI Q7 3.0 TDi Quattro [BUG] 03.2006-05.2008
AUDI Q7 3.0 TDi Quattro [BUN] 03.2006-05.2010
AUDI Q7 3.0 TDi Quattro [CASA] 11.2007-05.2012
AUDI Q7 3.0 TDi Quattro [CASA] 11.2007-08.2015
AUDI Q7 3.0 TDi Quattro [CASB] 03.2006-05.2010
AUDI Q7 3.0 TDi Quattro [CATA] 06.2009-05.2012
AUDI Q7 3.0 TDi Quattro [CCMA] 11.2007-05.2012
AUDI Q7 3.0 TDi Quattro [CCMA] 11.2007-08.2015
AUDI Q7 3.0 TDi Quattro [CJGA] 11.2007-05.2012
AUDI Q7 3.0 TDi Quattro [CJGA] 11.2007-08.2015
AUDI Q7 3.0 TDi Quattro [CJGC] 05.2010-08.2015
AUDI Q7 3.0 TDi Quattro [CJGD] 05.2011-08.2015
AUDI Q7 3.0 TDi Quattro [CJMA] 05.2010-08.2015
AUDI Q7 3.0 TDi Quattro [CJMA] 11.2010-08.2015
AUDI Q7 3.0 TDi Quattro [CLZB] 05.2011-08.2015
AUDI Q7 3.0 TDi Quattro [CNRB] 11.2007-08.2015
AUDI Q7 3.0 TDi Quattro [CRCA] 05.2011-08.2015
AUDI Q7 3.0 TDi Quattro [CRTE] 05.2015-12.2019
AUDI Q7 3.0 TDi Quattro [CZZA] 05.2015-12.2019
AUDI Q7 3.0 TDi Quattro [CZZA] 08.2015-12.2019
AUDI Q7 3.0 TDi Quattro [CZZB] 08.2015-12.2019
AUDI Q7 3.0 TFSi Quattro [CJTB] 05.2010-08.2015
AUDI Q7 3.0 TFSi Quattro [CJTC] 05.2010-08.2015
AUDI Q7 3.0 TFSi Quattro [CJWB] 05.2010-08.2015
AUDI Q7 3.0 TFSi Quattro [CJWC] 05.2010-08.2015
AUDI Q7 3.0 TFSi Quattro [CNAA] 05.2010-08.2015
AUDI Q7 3.0 TFSi Quattro [CTWA] 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro BUG 03.2006-05.2008
AUDI Q7 (4LB) 3.0 TDI quattro BUN 03.2006-05.2010
AUDI Q7 (4LB) 3.0 TDI quattro CASA 11.2007-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CASB 03.2006-05.2010
AUDI Q7 (4LB) 3.0 TDI quattro CATA 06.2009-05.2012
AUDI Q7 (4LB) 3.0 TDI quattro CCMA 11.2007-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CJGA 11.2007-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CJGC 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CJGD 05.2011-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CJMA 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CLZB 05.2011-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CNRB 11.2007-08.2015
AUDI Q7 (4LB) 3.0 TDI quattro CRCA 05.2011-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CJTB 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CJTC 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CJWB 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CJWC 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CNAA 05.2010-08.2015
AUDI Q7 (4LB) 3.0 TFSI quattro CTWA 05.2010-08.2015
AUDI Q7 (4MB, 4MG, 4MQ) 3.0 TDI quattro CRTE 05.2015-12.2019
AUDI Q7 (4MB, 4MG, 4MQ) 3.0 TDI quattro CZZA 05.2015-12.2019
AUDI Q7 (4MB, 4MG, 4MQ) 3.0 TFSI quattro CREC 01.2015-12.2019
AUDI Q7 Van (4LB) 3.0 TDI quattro BUG 03.2006-05.2008
AUDI Q7 Van (4LB) 3.0 TDI quattro BUN 03.2006-05.2010
AUDI Q7 Van (4LB) 3.0 TDI quattro CASA 11.2007-05.2012
AUDI Q7 Van (4LB) 3.0 TDI quattro CASB 03.2006-05.2010
AUDI Q7 Van (4LB) 3.0 TDI quattro CCMA 11.2007-05.2012
AUDI Q7 Van (4LB) 3.0 TDI quattro CJGA 11.2007-05.2012
AUDI Q7 Van (4LB) 3.0 TDI quattro CJMA 11.2010-08.2015
AUDI Q7 Van (4LB) 3.0 TDI quattro CLZB 05.2011-08.2015
AUDI Q7 Van (4LB) 3.0 TDI quattro CRCA 05.2011-08.2015
AUDI Q7 Van (4MB, 4MG) 3.0 TDI quattro CZZA 08.2015-12.2019
AUDI Q7 Van (4MB, 4MG) 3.0 TDI quattro CZZB 08.2015-12.2019
AUDI S5 3.0 Quattro Sportback [CAKA] 01.2010-01.2017
AUDI S5 3.0 Quattro Sportback [CGWC] 01.2010-01.2017
AUDI S5 3.0 Quattro Sportback [CREC] 01.2010-01.2017
AUDI S5 3.0 Quattro Sportback [CTDA] 01.2010-01.2017
PORSCHE Cayenne 3.0 D [M05.9E] 06.2010-
PORSCHE Cayenne 3.0 D [MCN.RB] 06.2010-
PORSCHE Cayenne 3.0 D [MCR.CB] 06.2010-
PORSCHE Cayenne 3.0 D [MCV.VA] 10.2014-
PORSCHE Cayenne 3.0 D [MCV.VB] 08.2014-
PORSCHE Cayenne 3.0 D [MCV.VC] 06.2010-
PORSCHE Cayenne 3.0 TDi [M05.9D] 02.2009-09.2010
PORSCHE CAYENNE (92A) 3.0 Diesel M05.9E 06.2010-
PORSCHE CAYENNE (92A) 3.0 Diesel MCN.RB 06.2010-
PORSCHE CAYENNE (92A) 3.0 Diesel MCR.C 06.2011-
PORSCHE CAYENNE (92A) 3.0 Diesel MCR.CA 06.2011-
PORSCHE CAYENNE (92A) 3.0 Diesel MCR.CB 06.2010-
PORSCHE CAYENNE (92A) 3.0 Diesel MCV.VA 10.2014-
PORSCHE CAYENNE (92A) 3.0 Diesel MCV.VB 08.2014-
PORSCHE CAYENNE (92A) 3.0 Diesel MCV.VC 06.2010-
PORSCHE CAYENNE (9PA) 3.0 TDI M05.9D 02.2009-09.2010
PORSCHE PANAMERA (970) 3.0 D MCR.CC 08.2011-07.2013
VW Touareg 3.0 TDi [BUN] 04.2006-05.2010
VW Touareg 3.0 TDi [CASB] 04.2006-05.2010
VW Touareg 3.0 TDi 4motion [CRCA] 05.2011-12.2014
VW Touareg 3.0 V6 TDi [BKS] 11.2004-05.2010
VW Touareg 3.0 V6 TDi [CASA] 01.2010-03.2018
VW Touareg 3.0 V6 TDi [CASA] 11.2007-05.2010
VW Touareg 3.0 V6 TDi [CASC] 11.2007-05.2010
VW Touareg 3.0 V6 TDi [CASD] 01.2010-03.2018
VW Touareg 3.0 V6 TDi [CATA] 06.2010-03.2018
VW Touareg 3.0 V6 TDi [CATA] 11.2004-05.2010
VW Touareg 3.0 V6 TDi [CJGD] 05.2011-03.2018
VW Touareg 3.0 V6 TDi [CJMA] 01.2010-03.2018
VW Touareg 3.0 V6 TDi [CNRB] 01.2010-03.2018
VW Touareg 3.0 V6 TDi [CRCA] 05.2011-03.2018
VW Touareg 3.0 V6 TDi [CRCD] 01.2010-03.2018
VW Touareg 3.0 V6 TDi [CVVA] 09.2014-03.2018
VW Touareg 3.0 V6 TDi [CVWA] 01.2010-03.2018
VW Touareg 3.0 V6 TSi Hybrid [CGEA] 04.2010-03.2018
VW Touareg 3.0 V6 TSi Hybrid [CGFA] 04.2010-03.2018
VW TOUAREG (7LA, 7L6, 7L7) 3.0 TDI BUN 04.2006-05.2010
VW TOUAREG (7LA, 7L6, 7L7) 3.0 TDI CASB 04.2006-05.2010
VW TOUAREG (7LA, 7L6, 7L7) 3.0 V6 TDI BKS 11.2004-05.2010
VW TOUAREG (7LA, 7L6, 7L7) 3.0 V6 TDI CASA 11.2007-05.2010
VW TOUAREG (7LA, 7L6, 7L7) 3.0 V6 TDI CASC 11.2007-05.2010
VW TOUAREG (7LA, 7L6, 7L7) 3.0 V6 TDI CATA 11.2004-05.2010
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CASA 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CASD 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CATA 06.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CJGD 05.2011-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CJMA 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CNRB 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CRCA 05.2011-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CRCD 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CVVA 09.2014-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TDI CVWA 01.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TSI Hybrid CGEA 04.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.0 V6 TSI Hybrid CGFA 04.2010-03.2018
VW TOUAREG (7P5, 7P6) 3.6 V6 FSI CGRA 04.2010-03.2018
VW TOUAREG VAN (7P5) 3.0 TDI 4motion CRCA 05.2011-12.2014

S6156 - Can use this to replace the S0270. The S6156 is for START/STOP applications but will work fine in the standard application

S6156(DENSO) - Can use this to replace the S0270. The S6156(DENSO) is for START/STOP applications but will work fine in the standard application

The pinion gear looks different to the S0270, But the pinion is LARGER and  the OFFSET is different, Because of this it can fit in place of the S0270. THE S0270 IS NOT FOR START/STOP

0001125519BOSCH
0001125521BOSCH
0001125609BOSCH
0001125610BOSCH
0001125650BOSCH
056911024JVW
059911024CVW
059911024EVW
059911024EXVW
059911024HVW
059911024HXVW
0986024050BOSCH
10010421AVITAB AUTOMOTIVE
10010421OVITAB AUTOMOTIVE
10439518ALANKO
106949FARCOM
11024050EUROTEC
114775CARGO
115502CARGO
12280EAI
13262MAPCO
17678NWAI
1986S00824BOSCH
20401124BNREAL
20401124OEREAL
25-4002CTAINDE
25-4297ELSTOCK
254373KUHNER
254373BKUHNER
254373SKUHNER
280ST21STARTCAR
2S0093RIDEX
300.586.093.010WAI
300.586.093.212WAI
300.586.093.215WAI
300.586.093.280WAI
300.586.093.395WAI
300.586.093.460WAI
300.586.093.461WAI
311282092DRI
3116944HENKEL PARTS
3116945HENKEL PARTS
3116946HENKEL PARTS
332111LOGISTIK
3384CEVAM
42024050HERTH+BUSS
458920VALEO
5010963GMEAT & DORIA
6010421.0SANDO
6010421.1SANDO
88213966POWERMAX
8EA011611-881HELLA
91-15-7318WILSON
95560410800PORSCHE
955604108XPORSCHE
A24050ATL AUTOTECHNIK
AC-CBS5743ACAUTO
AM-2950AUTO MAGNETO
AZMT-53-010-1048A.Z. MEISTERTEILE
BOS0001125609WOODAUTO
CGB-23130AINDE
CMA-621405COMLINE
CST10421ASCASCO
CST10421GSCASCO
F032114775CARGO
F032115502CARGO
LES0528LE PART
LRS02624LUCAS
LRS2624LUCAS
PRSS2373EFFE
S0270AS-PL
S12BH0931SIDAT
S132.068WAI
S144.840WAI
S148.699WAI
SBO421AUTOTEAM
SBO421AAUTOTEAM
SEG0001125609WOODAUTO
SG0579GHIBAUDI
SKSTR-0330092STARK
ST01795TMI
STB4519KRAUF
STR1585ELECTROLOG
STR50540WOODAUTO
STRS2373EFFE
STX200189RSTARDAX
TT16496TESLA TECHNICS
V10-12-25609VEMO
VW9111SNRA
WOOSTR50540WOODAUTO
S0270

THE S0270 IS NOT FOR START/STOP
