Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 245.85 including GST
NZ$ 213.78 excluding GST
or four payments of $61.46
with
Learn More
each
S2019
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
S114653Associated Numbers
112373 119226-77010 119226-77011 18055N 201356 201356H 20445931BN 20445931OE 25-3069 6020139 8212303 8508 8EA738258-221 AM878176 AM878813 CST20139 CST20139AS CST20139ES CST20139GS CST20139OS CST20139RS DRS0065 EAA-121343 JS1356 LRS01568 S114-443 S114-443A S114-653 S114-653A S114-653B STR-3800 STR23002 16131 16-131 hxs072 Hitachi HST114653B Wilson 91251109 References: Arrowhead SHI0108 JANNCO 41044018R Delco 10461660 S114443 S114443A S114653 S114653A S114653B STR0039 John Deere SE501846 Lester 18055 PIC Picture ID 104276A Yanmar 11922577011 11922677010 119226077010 712518055 91251113 CARGO CASCO CEVAM DELCO EAA121343 EAA 253069 ELSTOCK HC PARTS 8EA738258221 HELLA HITACHIList JOHN DEERE LUCAS POWERMAX REAL SANDO STR3800 UNIPOINT WAI / TRANSPO WOODAUTO YANMARList 11922677011 YANMAR 104276 11040798 EuroTec 112186 Cargo 11922577010 12922677011 18055R 18318N 21948HI Elstock 91251149 980506082 PSH A78590 ATL A90400 AM875014 AM878168 Casco Remy F042004011 Bosch HJS1356 Lucas M802137 S114613 S114613A S114652 STM779 Rolling Components STR3120sa Electrolog STR3801 Unipoint UD15043S ASPL CST20167 DRS0064 DS1174 253144 136960 HITACHI 2506960 S114813 S114816 S114816A LRS01619 980.536.082 20445761 10410244 ROBERT'S 6020167 11923377010 910064 EDR 980536082 CST20167AS CST20167GS snj400 7030111 ARROWHEAD Atlantic Quality Parts 1100-0133 2800-0101 BARSANCO 600-012 BELLIER 00000414 DVMBY08 UTMBY08 CHATENET 0117071 DIXIE NEW 243-12122 S-8555 DUBOIS 918055 EMP 4-6935 IAT SHY653 J&N Electrical Products 410-44018 KOMATSU YM119225-77011 YM119226-77010 LESTER ELECTRICAL EUROPE MICROCAR 1005066 MINNPAR 57-2496 HOLLAND VV11922677010 NSA STR-3801 104-276 104-276A RCP ST-18055 TAKEUCHI T11922577010 TUCKER ROCKY 495798 49-5798 2-1948-HI WILSON HD 91-25-1109 SMALL ENGINE 71-25-18055 WOOD AUTO 119225-77010 119225-77011Specifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 191 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 8 qty |
| No./Teeth (Replaces) | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 12 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 80 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YANMAR | 3TN63 | 10.1995- | |
| YANMAR | 3TN66 | 10.1995- | |
| YANMAR | 3TNE68 | 10.1995- |
Reference Information
| 003-MC004 | ASHIKA |
| 112186 | CARGO |
| 112373 | CARGO |
| 119225-77010 | YANMAR |
| 119225-77011 | YANMAR |
| 119226-77010 | YANMAR |
| 11922677011 | YANMAR |
| 12922677011 | YANMAR |
| 136953 | HITACHI |
| 18055N | WAI / TRANSPO |
| 201356 | KUHNER |
| 201356H | KUHNER |
| 20445931BN | REAL |
| 20445931OE | REAL |
| 2506953 | HITACHI |
| 25-3069 | ELSTOCK |
| 3MC004 | JAPKO |
| 41922677010 | YANMAR |
| 6020139 | SANDO |
| 8212303 | POWERMAX |
| 8508 | CEVAM |
| 8EA738258-221 | HELLA |
| 980.506.082.080 | PSH |
| 980.506.082.088 | PSH |
| 980.506.082.515 | PSH |
| AM875014 | JOHN DEERE |
| AM878176 | JOHN DEERE |
| AM878813 | JOHN DEERE |
| AM880978 | JOHN DEERE |
| CGB-23096 | AINDE |
| CQ1040363 | LAUBER |
| CST20139 | CASCO |
| CST20139AS | CASCO |
| CST20139ES | CASCO |
| CST20139GS | CASCO |
| CST20139OS | CASCO |
| CST20139RS | CASCO |
| DRS0065 | DELCO |
| F032112186 | CARGO |
| F032112373 | CARGO |
| F042004011 | BOSCH |
| HST114443A | HITACHI |
| HST114653B | HITACHI |
| JS1356 | HC PARTS |
| LRS01568 | LUCAS |
| LRS1568 | LUCAS |
| MAV221390 | SIOM |
| MTMC004 | JAPANPARTS |
| RNLS114-653 | RNL |
| S114-443 | HITACHI |
| S114-443A | HITACHI |
| S114652 | HITACHI |
| S114-653 | HITACHI |
| S114-653A | HITACHI |
| S114-653B | HITACHI |
| S12HT0819A2 | SIDAT |
| S136.259 | PSH |
| S2019 | AS-PL |
| SE501846 | JOHN DEERE |
| STR23002 | WOODAUTO |
| STR3120 | ELECTROLOG |
| STR-3800 | UNIPOINT |
| STRS035 | 3EFFE |
| STX200382 | STARDAX |
| STX200382R | STARDAX |
Video/Publications
