Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 398.81 including GST
NZ$ 346.79 excluding GST
or four payments of $99.70
with
Learn More
each
S2055
1
- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
Associated Numbers
581001290 8943334380 S25-21 UD02139S ASPL S2521 HITACHI ISUZU 16-108 16-926Specifications
| Kilowatt | 3.20 kW |
| Length (L.1) | 240 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 19.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 95 mm |
| Unit Type | HITACHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Elf 3.3 | [4BC2] | 01.1982-12.1987 |
| ISUZU | Npr 3.3 | [4BC2] | 01.1982-12.1987 |
Reference Information
| 581001290 | ISUZU |
| 8943334380 | ISUZU |
| MAV226040 | SIOM |
| S25-21 | HITACHI |
| UD02139S | AS-PL |
Video/Publications
