Information
28100E0080Associated Numbers
0365-502-0017 16-147 28100-E0080 28100E0080 70-8763 S9076 SXS713 281002894A 03655020016 2810078113 16-671 03655020027 281002891A 281002892A 281002894 2810078110 2810078111 2810078112 2810078113B QDJ2608 KRAUF STN8112WD STW8112LP STW8112TJ STW8112WD STW8112YJ STW9112NL Motorherz STW8112WA STW9112WA Sawafuji 03655020013 03655020017 03655020019 03655020023 03655020026 03655020029 03655020141 Toyota WAI 2-8100-HN WPS 19271N dxs4026 sxs713 sxs725 SNJ154 7087633 03655020146 03655020147 191518112 PSH Hino Lester 19271 PIC Picture ID 185399 ASPLList ASHDOWN INGRAM 708763 CIVIC/DA PARTS HINOList 16147 PAN PACIFIC SAWAFUJI Armature G Roy EGI S19271 2810078113A Part # Powerite Automotive 03655020028 New Mondial 7589390 Our Number Power Select Raw Road Warrior Techno CVC IND2870017 03656020016 03656020017 03656020018 281002865 281002862 281002863 03656020011 03656020012 0365602001 281002894STW8112STW91120365502001303655020017 036550200260365502002703655020029 28100-78180 03655020132 28100-2322A 28100-2322B 28100-2324 28100-2622B 28100-2624B 28100-2625 28100-2625A 28100-78061 28100-78062A 28100-78063 0350-502-0210 0350-502-0211 0350-502-0212 0350-502-0213 0350-502-0214 0355-502-0014 0355-502-0017 0355-502-0018 0355-502-0019 0355-502-0025 0355-502-0027 0355-502-0028 0355-502-0040 0355-502-0050 03505020264 281002710e
28100-e0612
0365-502-0193
0365-502-0192
Specifications
| Kilowatt | 5 kW |
| Length (L.1) | 271 mm |
| Mount Hole Center - Center (O.1) | 141 mm |
| Mount Hole Diameter (C.1) | M14x1.5 mm |
| Mount Hole Diameter (C.2) | 15.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 29 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | SAWAFUJI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HINO | Engine |
Alternatives >>>
S9128 - 4.5kW option, most common size fitted
Reference Information
| 0365-502-0013 | SAWAFUJI |
| 0365-502-0017 | SAWAFUJI |
| 0365-502-0141 | SAWAFUJI |
| 0365-502-0146 | SAWAFUJI |
| 0365-502-0147 | SAWAFUJI |
| 0365-502-0390 | SAWAFUJI |
| 16-147 | PAN PACIFIC |
| 191.518.112.138 | PSH |
| 191.518.112.140 | PSH |
| 191.518.112.540 | PSH |
| 19271N | WAI / TRANSPO |
| 20444706BN | REAL |
| 20444706OE | REAL |
| 281002891A | HINO |
| 281002894 | HINO |
| 2810078112 | HINO |
| 2810078112 | TOYOTA |
| 28100E0080 | HINO |
| 6037607.0 | SANDO |
| 6037607.1 | SANDO |
| 70-8763 | CIVIC/DA PARTS |
| CST37607AS | CASCO |
| CST37607GS | CASCO |
| MAV396070 | SIOM |
| QDJ2608 | DONGFENG |
| S131.532 | PSH |
| S145.785 | PSH |
| S9076 | AS-PL |
| STR75615 | WOODAUTO |
| STR9886 | ELECTROLOG |
| SXS713 | ASHDOWN INGRAM |
Video/Publications
