Information
1196601Associated Numbers
115571 1196601 12286 19491N 220712 25-4395 25183761 25383761 255041 255041V 3250 4802243 6032141 830.919.093 AEY2803 CST32141 CST32141AS CST32141ES CST32141GS CST32141OS CST32141RS DRS0827 J5210919 LRS02803 S001196601 S3146 STR54187 UD12705S
STRF598 3EFFE
S3146 AS-PLList
UD12705S AS-PL
AEY2803 AUTOELECTRO
115571 CARGO
CST32141 CASCO
CST32141AS CASCO
CST32141ES CASCO
CST32141GS CASCO
CST32141OS CASCO
CST32141RS CASCO
3250 CEVAM
25183761 CHEVROLET
25383761 CHEVROLET
DRS0827 DELCO
12286 EAI
25-4395 ELSTOCK
220712 ERA
J5210919 HERTH+BUSS
255041 KUHNER
255041V KUHNER
LRS02803 LUCAS
LRS2803 LUCAS
4802243 OPELList
830.919.093 PSH
RNL25183761 RNL
6032141 SANDO
1196601 VALEOList
600708 VALEOList
S001196601 VALEOList
19491N WAI / TRANSPO
STR54187 WOODAUTO
S3146 ASPLList
UD12705S ASPL
AEY2803 AUTOELECTRO
115571 CARGO
CST32141 CASCO
3250 CEVAM
25183761 CHEVROLET
25383761 CHEVROLET
DRS0827 DELCO
12286 EAI
254395 ELSTOCK
220712 ERA
J5210919 HERTH+BUSS
LRS02803 LUCAS
4802243 OPELList
830.919.093 PSH
6032141 SANDO
1196601 VALEOList
S001196601 VALEOList
19491N WAI / TRANSPO
STR54187 WOODAUTO
UD12711S ASPL
115571 CARGO
CST32141 CASCO
3250 CEVAM
25183761 CHEVROLET
DRS0827N DELCO
12286 EAI
254395 ELSTOCK
220712 ERA
J5210919 HERTH+BUSS
LRS02803 LUCAS
4802243 OPELList
830.919.093 PSH
6032141 SANDO
1196601 VALEOList
S001196601 VALEOList
19491NOS WAI / TRANSPO
STR54187 WOODAUTO
vxs915 vxs915U 7062851 snv024 snv024GQ
11090290 EuroTec
115571 Cargo
1196601
12286 EAI
19491 Lester
19491N WAI
19491NOS WAI
19491R WAI
25183761 Opel
3250 CEVAM
830919093 PSH
910827 EDR
DRS0827 Remy
LRS02803 Lucas
OSM12036 Optimum
S0001196601 Valeo
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 237 mm |
| Mount Hole Center - Center (O.1) | 104.5 mm |
| Mount Hole Center - Center (O.2) | 33 mm |
| Mount Hole Center - Center (O.3) | 112.5 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 22 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Captiva 2.2 D | [Z22D1] | 03.2011- |
| CHEVROLET | Captiva 2.2 D 4x4 | [A22DMH] | 03.2011- |
| CHEVROLET | Captiva 2.2 D 4x4 | [Z22D1] | 03.2011- |
| CHEVROLET | Cruze 2.0 CDi | [LNP] | 08.2010- |
| CHEVROLET | Cruze 2.0 CDi | [Z20D1] | 06.2011- |
| CHEVROLET | Cruze 2.0 CDi | [Z20D1] | 08.2010- |
| CHEVROLET | Cruze 2.0 TD | [LNP] | 08.2012- |
| CHEVROLET | Orlando 2.0 VCDi | [Z20D1] | 02.2011- |
| OPEL | Antara 2.2 CDTi | [A22DM] | 12.2010- |
| OPEL | Antara 2.2 CDTi 4x4 | [A22DM] | 12.2010- |
| OPEL | Antara 2.2 CDTi 4x4 | [A22DMH] | 12.2010- |
| VAUXHALL | Antara 2.2 CDTi | [A22DM] | 12.2010- |
| VAUXHALL | Antara 2.2 CDTi | [A22DMH] | 12.2010- |
Reference Information
220712 STR0485 S-54187 10032141AV LES0627 IR8405 5015128 830.919.093.460 830.919.093.340 WOOSTR54187 20493141OE S102044 SMA141A 11090290 S102043 220712A 328074092 13047884 20493141BN 6032141.0 336032 S3146 SMA141 6032141.1 RAS31938 UD12705S 25183761 12286 8EA011612-121 LRS2803 DS1937 3250 STA4802 VAL600708 S001196601 CST32141GS 95520319 1196601 286ST21 10438888 RNL25183761 TT16736 458765 WG2013276 STRF598 WG2013275 3126348 WG2196684 3126349 F032115571 107753 J5210919 A92090 830.919.093.000 255041 25-4395CT 830.919.093.360 S12VA0125 DRS0827N 10032141OV 4736006 S105170 AC-CBS5838 25383761 25-4395 AZMT-53-010-1423 4802243 ST01885 OP9045 600708 S12VA0125A2 DRS0827 1202487 115571 255041V 19491N SG2107 3126350 CGB-23242 LRS02803 CST32141AS SG2107RB STR54187Video/Publications
