Associated Numbers
114340 190-25193 19846N 20432616BN 228000-0630 228000-0631 228000-0632 228000-0651 228000-1750 228000-1751 228000-1752 228000-1753 228000-4990 228000-4991 228000-4992 228000-6640 228000-6670 228000-6671 228000-9330 246-25216 254133 254133D 254133K 254133L 3863128 3920644 3957592 428000-1830 45-4409 600-813-4110 600-813-4130 600-813-5110 600-863-4110 600-863-4130 600-863-4210 6040616 673-181-2530 673-381-6510 673-382-6510 8221 941.511.102 CST40616AS EAA-111529 LRS02736 S-8543 S6144 STN4340 STR30051 STR75206Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 296 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JCB | 434S 6.7 | [QSB] | 01.2007- |
| JCB | 436E 6.7 | [6BTAA] | 01.2007- |
| KOMATSU | WA120 4B | 01.1997-01.2006 | |
| KOMATSU | WA120 4B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA120 6B | 01.1997-01.2006 | |
| KOMATSU | WA120 6B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA180 4B | 01.1997-01.2006 | |
| KOMATSU | WA180 4B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA180 6B | 01.1997-01.2006 | |
| KOMATSU | WA180 6B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA250 4B | 01.1997-01.2006 | |
| KOMATSU | WA250 4B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA250 5.9 | [S6D102] | 01.1997- |
| KOMATSU | WA250 6B | 01.1997-01.2006 | |
| KOMATSU | WA250 6B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA253 4B | 01.1997-01.2006 | |
| KOMATSU | WA253 4B Wheelloader | 01.1997-01.2006 | |
| KOMATSU | WA253 6B | 01.1997-01.2006 | |
| KOMATSU | WA253 6B Wheelloader | 01.1997-01.2006 |
Reference Information
228000-0630 6731812530 228000-0631 DS1467 STR30051 228000-0632 190-25122 4064168 LRS2736 228000-4991 DSN2106 6040616 228000-4992 228000-4990 STR6788 6040616.1 5140097 941.511.102.260 941.558.102.260 600-813-5110 45-4409 673-381-6510 428080-1831 STN4340 428000-1830 STRL225 UD100737S 336191 428000-1831 3957592 3957593 STN8340 941.511.102.059 DENDSN2106 PRSL225 CST40616GS 254133L 114340 254133 18402N 336185 254133K 254133D 600-863-4130 673-382-6510 3575248RX 600-863-4211 600-863-4210 STN9340 941.511.102.200 6731816510 3922474 228000-6670 673-181-2530 336495 20432616OE DRS0357 20432616BN MAV426160 LRS02736 LES0257 228000-1752 228000-1753 90032116 CGB-26640 S6144 CST40616AS 941.511.102.310 3863128 3920644 228000-6640 3970101 228000-1750 228000-1751 3864298 STK4340 600-813-4130 600-863-4110 3675248RX 3934119 6733816510 600-863-4111Video/Publications
114340 18402N 190-25122 20432616BN 228000-0630 228000-0631 228000-0632 228000-1750 228000-1751 228000-1752 228000-1753 228000-4992 228000-6670 246-25216 254133 254133C 254133D 254133L 3920644 3957592 428000-1830 45-4409 600-813-4110 600-813-4130 600-813-5110 6040616.0 8221 90032116 941.511.102.200 941.511.102.260 941.511.102.310 CGB-26640 CST40616AS DRS0357 DS1467 LES0257 LRS02736 LRS2736 MAV426160 PRSL225 S-8543 S6144 STK4340 STN4340 STN8340 STN9340 STR30051 STR75206 STRL225Add Your Number
