Associated Numbers
14044 14-044
AEA2241 AUTOELECTRO
0986037531 BOSCH
112092 CARGO
CAL20197AS CASCO
9081 CEVAM
DRA3333 DELCO
EAA221821 EAA
56377 EAI
56604 EAI
281829 ELSTOCK
JA773IR HC PARTS
8EL730107001 HELLA
LR170406 HITACHI List
LR170406B HITACHI List
LR170406C HITACHI List
LR170406E HITACHI List
LR170406F HITACHI List
LR170414 HITACHI List
LR170414B HITACHI List
LR170414C HITACHI List
LR170414E HITACHI List
11.0773 LAUBER
LRA01936 LUCAS
2310006N00 NISSAN
23100G5700 NISSAN List
23100G5701 NISSAN List
23100G5702 NISSAN List
23100G5704 NISSAN List
89212532 POWERMAX
20130132 PRESTOLITE
SA023 SOVEREIGN
437731 VALEO
ALT30080 WOODAUTO
0986037531
165814070
2310006N00
23100G5700
23100G5701
23100G5702
23100G5704
90251151
9051142F
ADA382
ADA407
DRA3333
JA773IR
LR170406
LR170406B
LR170406C
LR170406E
LR170406F
LR170414
LR170414B
LR170414E
LRA01395
hxa007 653014 653015
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 16 mm |
| Length (L.1) | 255 mm |
| Mount Inside Length or Pad Mount C-C (C) | 79 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52 mm |
| Outside Diameter (O.D.2) | 84 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44.5 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | King Vanette 2.0 Diesel | (GC22)[LD20] | 09.1986-11.1991 |
| NISSAN | Vanette 2.0 Diesel | (C22)[LD20] | 09.1986-03.1993 |
Alternatives >>>
A2014 - Double Vee Pulley Option
