Associated Numbers
0001108208 BOSCHList 0001108460 Bosch 0001108209 0001108461 0986021157 ruil 0986021980 11090144 EuroTec 1206169 PIC 12160 EAI 12417525293 BMW 12417525445 12417536690 PRSL802 3EFFE STRL802 CGB-53372 AINDE UD17317S AS-PL AEY2201 AUTOELECTRO 12417610344 12417610351 7525293 7536690 BOSCH CST10003GS CASCO DRS0087 DELCO DS1197 RAS31198 S-6258 DIXIE EAA-121477 EAA 25-3372 ELSTOCK EUROTEC STB4808 KRAUF 254211 KUHNER LRS02201 LUCAS LRS2201 88214285 POWERMAX 210.526.092 PSH 20401300OE REAL S80277N ROTOVIS 6010003.1 SANDO MAV120030 SIOM 458828 VALEO 17923N WAI / TRANSPO BOS0001108460 WOODAUTO STR50268 WRM10003OE WROOM snb0072 70-1304 bxs0161 show 17923 Lester 210526092 253372 Elstock 3186 CEVAM 8080277F Friesen 910087 EDR Remy Lucas SR0809N (USA) SR0809X Wilson 91-15-7222 References: 12-41-7-525-293 12-41-7-536-690 12-41-7-537-513 Picture ID 120-6169 410-24117 J N 17923R STM1203 Rolling ComponentsSpecifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 545 4.4 i | (E60)[M62B44] | 01.2003-12.2005 |
| BMW | 545 4.4 i | (E61)[M62B44] | 01.2003-12.2005 |
| BMW | 550 4.8 i | (E60)[N62B48B] | 01.2005- |
| BMW | 550 4.8 i | (E61)[N62B48B] | 01.2005- |
| BMW | 645 4.4 Ci | (E63)[M62B44] | 01.2004-12.2005 |
| BMW | 645 4.4 Ci | (E64)[M62B44] | 01.2004-12.2005 |
| BMW | 650 4.8 i | (E63)[N62B48B] | 01.2005- |
| BMW | 650 4.8 i | (E64)[N62B48B] | 01.2005- |
| BMW | 750 5.0 i | (E65)[N62B48B] | 01.2005- |
| BMW | X5 4.4 i | (E53)[N62B44] | 01.2003- |
| BMW | X5 4.8 i | (E53)[N62B48A] | 01.2004-12.2006 |
| BMW | X5 4.8 i | (E70)[N62B48A] | 01.2007- |
| BMW | X5 4.8 xDrive 48 i | (E70)[N62B48B] | 01.2008- |
Alternatives >>>
S0391 - Brand new aftermarket version
