Information
A3TJ1191Associated Numbers
UD11022A AS-PL
CAL35282 CASCO
CAL35282GS CASCO
12841 DELCO
A-80259 DIXIE
L33G18300 MAZDA
L33G18300A MAZDA
A3TJ1191 MITSUBISHI List
145.556.110 PSH
20137282OE REAL
11330N WAI / TRANSPO
90-27-3383 WILSON
11330
11330N
145556110
2035138
90273383
A003TJ1191
A3TJ1191
L33G18300
L33G18300A
LRA04025
TNA021
Substitutes:
Remy Light Duty 12841
Wilson 90-27-3383
References:
Arrowhead AMT0231
Bosch AL4240X
Lester 11330
Mazda L33G18-300, L33G18-300A, L33G18-300R0A
Mitsubishi A3TJ1191
PIC Picture ID 203-5138
Remy Light Duty 12841
Wilson 90-27-3383
anj548GQ 656662 656665
UD11022A ASPL
CAL35282 CASCO
CAL35282GS CASCO
12841 DELCO
A80259 DIXIE
L33G18300 MAZDA
L33G18300A MAZDA
A3TJ1191 MITSUBISHI List
145.556.110 PSH
20137282OE REAL
11330N WAI / TRANSPO
90273383 WILSON
11330
11330N
145556110
2035138
90273383
A003TJ1191
A3TJ1191
L33G18300
L33G18300A
LRA04025
TNA021
Substitutes:
Remy Light Duty 12841
Wilson 90273383
References:
Arrowhead AMT0231
Bosch AL4240X
Lester 11330
Mazda L33G18300, L33G18300A, L33G18300R0A
Mitsubishi A3TJ1191
PIC Picture ID 2035138
Remy Light Duty 12841
Wilson 90273383
anj548GQ 656662 656665
Specifications
Amp | 110 A |
Diameter (D.1) | 10.50 mm |
Diameter (D.2) | 10.50 mm |
Diameter (D.3) | 12.50 mm |
Length (L.1) | 182 mm |
Mount Inside Length or Pad Mount C-C (C) | 74 mm |
OEM Product | No |
Pad mount thickness (E.1) | 60 mm |
Pad mount thickness (E.2) | 60 mm |
Pad mount thickness (E.3) | 60 mm |
Plug Code | PL_3310 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 40.50 mm |
Pulley Type | Solid |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | 5 2.5 | 01.2012-12.2014 | |
MAZDA | CX-7 2.3 | [L3-VDT] | 01.2007-12.2012 |
MAZDA | CX-7 2.3 AWD | [L3-VDT] | 06.2006-12.2012 |
MAZDA | CX-7 2.3 DISi | [L3K7] | 06.2006-06.2009 |
MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 06.2006-12.2014 |
MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 06.2009-03.2013 |
MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 10.2007-08.2009 |
MAZDA | CX-7 2.5 | 01.2010-12.2012 | |
MAZDA | CX-7 2.5 MZR | [L5-VE] | 07.2009-03.2013 |
Alternatives >>>
A5211- Brand new version with Clutch Pulley
Reference Information
11330N | WAI / TRANSPO |
145.556.110.130 | PSH |
145.556.110.138 | PSH |
145.556.110.370 | PSH |
20137282BN | REAL |
20137282OE | REAL |
2035282.0 | SANDO |
2035282.1 | SANDO |
27-7634 | ELSTOCK |
40487 | CEVAM |
89215240 | POWERMAX |
90-27-3383 | WILSON |
A003TJ1191 | MITSUBISHI |
A003TJ1191A | MITSUBISHI |
A003TJ1191AM | MITSUBISHI |
A3TJ1191 | MITSUBISHI |
A3TJ1191A | MITSUBISHI |
A3TJ1191AM | MITSUBISHI |
A5213 | AS-PL |
ALM0061 | KRAUF |
ALT31364 | WOODAUTO |
ALT372820 | SIOM |
ALT372820A | SIOM |
ALT5417 | ELECTROLOG |
ALTF901 | 3EFFE |
CAL35282AS | CASCO |
CAL35282GS | CASCO |
DRA1848 | DELCO |
L33G | MAZDA |
L33G-18-300 | MAZDA |
L33G-18-300A | MAZDA |
LRA04025 | LUCAS |
LRA4025 | LUCAS |
MITA3TJ1191 | WOODAUTO |
PRAF901 | 3EFFE |
UD11022A | AS-PL |
