- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- < Critical Notes >
Information
0001109413Associated Numbers
0001109413 0001218152 0001218168 0001218768 0001218814 0986016210 101201 10543 10590 112439 20401411BN 22.0997 22.1201 22.1201M 25-0080 25-3117 254093B 33091N 35259400 35259480 3677 436052 450.501.093 6010114 8212758 8816210 88212758 8EA011610-101 8EA737859-001 AES7128 B001233216 BOS0001109413 CS1201 CST10114AS DRS3084 EAA-121087 ERR5009 IS9437 LRS00728 NAD100390 NAD500210 STR54006 UD12023S VS104
UD12023S ASPL
AES7128 AUTOELECTRO
0001109413 BOSCHList
0001218152 BOSCHList
0001218168 BOSCHList
0001218768 BOSCHList
0001218814 BOSCHList
0986016210 BOSCH
B001233216 BOSCHList
112439 CARGO
CST10114AS CASCO
3677 CEVAM
DRS3084 DELCO
EAA121087 EAA
250080 ELSTOCK
253117 ELSTOCK
8816210 FRIESEN
CS1201 HC PARTS
8EA011610101 HELLA
8EA737859001 HELLA
IS9437 ISKRA / LETRIKA
22.0997 LAUBER
22.1201 LAUBER
22.1201M LAUBER
LRS00728 LUCAS
8212758 POWERMAX
88212758 POWERMAX
35259400 PRESTOLITE
35259480 PRESTOLITE
450.501.093 PSH
20401411BN REAL
ERR5009 ROVERList
NAD100390 ROVER
NAD500210 ROVER
6010114 SANDO
436052 VALEOList
VS104 VALEO
33091N WAI / TRANSPO
BOS0001109413 WOODAUTO
STR54006 WOODAUTO
S0042 ASPLList
UD12023S ASPL
AES7128 AUTOELECTRO
0001109413 BOSCHList
0001218152 BOSCHList
0001218168 BOSCHList
0001218768 BOSCHList
0001218814 BOSCHList
0986016210 BOSCH
B001233216 BOSCHList
112439 CARGO
CST10114AS CASCO
3677 CEVAM
DRS3084 DELCO
EAA121087 EAA
11264 EAI
250080 ELSTOCK
253117 ELSTOCK
8816210 FRIESEN
CS1201 HC PARTS
8EA011610101 HELLA
8EA737859001 HELLA
IS9437 ISKRA / LETRIKA
22.0997 LAUBER
22.1201 LAUBER
22.1201M LAUBER
LRS00728 LUCAS
8212758 POWERMAX
88212758 POWERMAX
35259400 PRESTOLITE
35259480 PRESTOLITE
450.501.093 PSH
20401411BN REAL
ERR5009 ROVERList
NAD100390 ROVER
NAD500210 ROVER
6010114 SANDO
SS689 SOVEREIGN
436052 VALEOList
VS104 VALEO
33091N WAI / TRANSPO
BOS0001109413 WOODAUTO
STR54006 WOODAUTO
bx109413
0001109413 Bosch
0001218152 Bosch
0001218168 Bosch
0001218768 Bosch
0051511501 Mercedes Benz
0986016210 Bosch ruil
105940 Valeo
11016210 EuroTec
11264 EAI
120231 PIC
252295 Elstock
27425 Lucas
27425B Lucas
27460 Lucas
33089N WAI
33091 Lester
33091N WAI
33091R WAI
35259400 Prestolite
3677 CEVAM
4055SP Spidan
4071SP Spidan
432539 Valeo
432574 Valeo
436052 Valeo
450501093 PSH
4658SP Spidan
8816210F Friesen
8EA011610101 Hella
9000331425 Bosch
913084 EDR
913593 EDR
B001233216 Bosch
BF5T11001AA Ford
CS1201 HC
CS543 HC
CS590 HC
CST10114 Casco
D9R91 Valeo
DRS3084 Remy
DRS3593 Remy
ERR4009 Rover Group
ERR5009 Rover Group
HCS1201 HC
HCS543 HC
LRS00574 Lucas
LRS00728 Lucas
LRS02088 Lucas
LRS574 Lucas
LRS728 Lucas
NAD10039 Rover Group
NAD100390 Rover Group
NAD500210 Rover Group
ND078 Valeo
OSM10516 Optimum
OSM10582 Optimum
OSM11155 Optimum
PRC5109 Rover Group
SM2605 Honda
STM904 Rolling Components
STR0003sa Electrolog
STR1091sa Electrolog
STR4085sa Electrolog
STR4109sa Electrolog
01331412 Andre Niermann
11090080 EuroTec
1205084 PIC
20500139 Prestolite
26256 Lucas
26259 Lucas
26321 Lucas
26321E Lucas
27446 Lucas
27468 Lucas
27468D Lucas
33088N WAI
33088R WAI
450009103 PSH
458589 Valeo
9000331412 Bosch
9000331413 Bosch
913464 EDR
A73480 ATL
A73590 ATL
A74140 ATL
CS997 HC
DRS3464 Remy
LRS00139 Lucas
LRS01390 Lucas
LRS01397 Lucas
LRS01398 Lucas
LRS139 Lucas
OSM10271 Optimum
SM1112
STM763 Rolling Components
STR4085sa Electrolog
STR4109sa Electrolog
UD12409S ASPL
AES1139 AUTOELECTRO
AES5174 AUTOELECTRO
0001218814 BOSCHList
0986016210 BOSCH
9000331412 BOSCHList
9000331425 BOSCHList
9004475107 BOSCH
CST10114 CASCO
CST25117 CASCO
CST25117AS CASCO
CST25117GS CASCO
3619 CEVAM
DRS3593 DELCO
0280004001 DENSO
EAA121087 EAA
EAA121837 EAA
BF5T11001AA FORDList
ERR5009 FORD
NAD500210 FORD
NNN500210 FORD
SG0144 GHIBAUDI
8EA012528191 HELLA
22.0590 LAUBER
22.0997 LAUBER
25024044 LUCAS
25024044A LUCAS
26256 LUCASList
26256D LUCAS
26256E LUCASList
26321A LUCASList
26925200A LUCASList
27425 LUCASList
27425A LUCASList
27425B LUCASList
27460 LUCASList
27460A LUCASList
27460B LUCASList
LRS00574 LUCAS
LRS574 LUCASList
NSB512 LUCAS
063227460 MAGNETI MARELLIList
63227460 MAGNETI MARELLIList
0051511501 MERCEDES
A0051511501 MERCEDES
20500139 PRESTOLITE
20500574 PRESTOLITE
35259400 PRESTOLITE
35259480 PRESTOLITE
450.501.093 PSH
20405711BN REAL
20405711OE REAL
PRC3032 ROVER
RTC5249 ROVER
6010114 SANDO
6025117 SANDO
SS652 SOVEREIGN
SS662 SOVEREIGN
33089N WAI / TRANSPO
UNIT BOM 1205084 WAI / TRANSPO
STR56004 WOODAUTO
UD12403S ASPL
AES1139 AUTOELECTRO
AES5174 AUTOELECTRO
110440 CARGO
CST25113 CASCO
CST25113AS CASCO
CST25113GS CASCO
DRS3464 DELCO
EAA121417 EAA
11608 EAI
250250 ELSTOCK
SG0162 GHIBAUDI
CS997 HC PARTS
8EA737246001 HELLA
26025198A LUCAS
26256 LUCASList
26259 LUCASList
26259A LUCASList
26259K LUCASList
26259L LUCASList
26259N LUCASList
26321 LUCASList
26321A LUCASList
26321B LUCASList
26321D LUCASList
26321F LUCASList
26925198 LUCAS
26925198A LUCAS
26925198D LUCASList
27425 LUCASList
27446 LUCASList
27446A LUCASList
27468 LUCASList
27468A LUCASList
27468B LUCASList
LRS00139 LUCASList
LRS139 LUCASList
NSB409 LUCAS
NSB511 LUCAS
63227468 MAGNETI MARELLIList
MSR183 MAGNETI MARELLI
8213323 POWERMAX
20500139 PRESTOLITE
450.009.103 PSH
20405311BN REAL
20405311OE REAL
18030174 ROBERT'S
GEU420 ROVER
6025113 SANDO
33088N WAI / TRANSPO
33088R WAI / TRANSPO
STR56003 WOODAUTO
S4059 S4009
01331412 Andre Niermann
11090080 EuroTec
1205084 PIC
20500139 Prestolite
26256 Lucas
26259 Lucas
26321 Lucas
26321E Lucas
27446 Lucas
27468 Lucas
27468D Lucas
33088N WAI
33088R WAI
450009103 PSH
458589 Valeo
9000331412 Bosch
9000331413 Bosch
913464 EDR
A73480 ATL
A73590 ATL
A74140 ATL
CS997 HC
DRS3464 Remy
LRS00139 Lucas
LRS01390 Lucas
LRS01397 Lucas
LRS01398 Lucas
LRS139 Lucas
OSM10271 Optimum
SM1112
STM763 Rolling Components
STR4085sa Electrolog
STR4109sa Electrolog
Specifications
| Kilowatt | 2.20 kW |
| Length (L.1) | 247 mm |
| Mount Hole Center - Center (O.1) | 147 mm |
| Mount Hole Center - Center (O.2) | 104 mm |
| Mount Hole Center - Center (O.3) | 104 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| Mount Hole Diameter (C.3) | 12 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 21 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Defender 110 2.5 TDi | [23L] | 09.1990-12.1998 |
| LAND ROVER | Defender 2.5 4WD | [10P] | 06.1998- |
| LAND ROVER | Defender 2.5 4WD | [15P] | 06.1998- |
| LAND ROVER | Defender 2.5 TD5 4WD | [10P] | 06.1998- |
| LAND ROVER | Defender 2.5 TD5 4WD | [14P] | 06.1998- |
| LAND ROVER | Defender 2.5 TD5 4WD | [15P] | 06.1998- |
| LAND ROVER | Defender 90 2.5 TDi | [23L] | 09.1990- |
| LAND ROVER | Defender 90 2.5 TDi | [23L] | 09.1990-12.1998 |
| LAND ROVER | Discovery 2.5 4x4 | [10P] | 11.1998-06.2004 |
| LAND ROVER | Discovery 2.5 TDi | [12L] | 10.1989-10.1998 |
| LAND ROVER | Land Rover 2.5 TD | [19J] | 09.1986-07.1990 |
| LAND ROVER | Range Rover 2.5 Diesel | [14L] | 08.1994-03.2002 |
| LAND ROVER | Range Rover 2.5 Diesel | [256T] | 07.1994-03.2002 |
| MERCEDES BENZ | Sprinter 412D | [OM.602.980] | 02.1996-05.2006 |
| MERCEDES BENZ | Sprinter 412D 4x4 | [OM.602.980] | 05.1997-05.2006 |
Reference Information
| 0001109413 | BOSCH |
| 0001218152 | BOSCH |
| 0001218168 | BOSCH |
| 0001218768 | BOSCH |
| 0001218814 | BOSCH |
| 003-H705 | ASHIKA |
| 0051511501 | MERCEDES |
| 0986016210 | BOSCH |
| 101201 | KUHNER |
| 10543 | KUHNER |
| 110354 | CARGO |
| 112439 | CARGO |
| 20401411BN | REAL |
| 220362 | ERA |
| 220883 | ERA |
| 22.0997 | LAUBER |
| 22.1201 | LAUBER |
| 22.1201M | LAUBER |
| 25-0080 | ELSTOCK |
| 25-3117 | ELSTOCK |
| 254093B | KUHNER |
| 33091N | WAI / TRANSPO |
| 35259400 | PRESTOLITE |
| 35259480 | PRESTOLITE |
| 3677 | CEVAM |
| 3H705 | JAPKO |
| 436052 | VALEO |
| 450.501.093 | PSH |
| 450.501.093.461 | PSH |
| 494285R | DAF |
| 6010114 | SANDO |
| 8212758 | POWERMAX |
| 8816210 | FRIESEN |
| 88212758 | POWERMAX |
| 8EA011610-101 | HELLA |
| 8EA737859-001 | HELLA |
| A0051511501 | MERCEDES |
| AES7128 | AUTOELECTRO |
| ALT3800 | SIOM |
| ANM15304X | ANDEL |
| B001233216 | BOSCH |
| BF5T11001AA | FORD |
| BOS0001109413 | WOODAUTO |
| CGB-23084 | AINDE |
| CS1201 | HC PARTS |
| CS543 | HC PARTS |
| CST10114AS | CASCO |
| DRS3084 | DELCO |
| ERR5009 | ROVER |
| ERR5009A | MAXION |
| ERR5009E | ROVER |
| EZ0546 | ELTA AUTOMOTIVE |
| F032110354 | CARGO |
| F032112439 | CARGO |
| IS9437 | ISKRA / LETRIKA |
| LR005962 | ROVER |
| LRS00728 | LUCAS |
| LRS728 | LUCAS |
| MAV121140 | SIOM |
| MS 12 | MAHLE |
| MTH705 | JAPANPARTS |
| NAD10039 | LAND ROVER |
| NAD10039 | ROVER |
| NAD100390 | ROVER |
| NAD500210 | ROVER |
| NNN500210 | FORD |
| PRC4425 | LAND ROVER |
| PRC5109 | LAND ROVER |
| PRC5109E | LAND ROVER |
| PRC5109N | LAND ROVER |
| S0537 | AS-PL |
| S12BH0788A2 | SIDAT |
| S12BH0795A2 | SIDAT |
| S132.645 | PSH |
| S144.998 | PSH |
| STM904 | ROLLCO |
| STR1567 | ELECTROLOG |
| STR54006 | WOODAUTO |
| STRF341 | 3EFFE |
| STRS013 | 3EFFE |
| STRS042 | 3EFFE |
| STX200303 | STARDAX |
| STX200447 | STARDAX |
| UD12023S | AS-PL |
| VS104 | VALEO |
Video/Publications
S0537< Critical Notes >
Replaces Lucas M45, M127, M50 type starters
Replaces Bosch '218' and '362' series starters
