Associated Numbers
UD14843A ASPLList
1042113470 DENSOList
1042113471 DENSO
2100809 DENSO
311005X6J01 HONDA
CSP47 HONDA
125.585.135 PSH
90295874 WILSON
1042113470 Denso
1042113471 Denso
125585135 PSH
21154 Lester
2905653 PIC
311005X6J01 Honda
311005X6J01RM Honda
Bosch AL1325X
Denso 1042113470, 2100809
Honda 311005X6J01, 311005X6J01RM, CSP47
Lester 21154
PIC Picture ID 2905653
Remy Light Duty 11227
Youtech/PartRef 335389
Wilson 90295874
Specifications
| Amp | 135 A |
| Bottom Mounting Foot Width (B) | 23 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 167 mm |
| Mount Inside Length or Pad Mount C-C (C) | 43 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 58 mm |
| Plug Code | PL_1000 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ACURA | ILX 2.4 | 01.2016-12.2016 | |
| ACURA | TLX 2.4 | 01.2015-12.2015 | |
| ACURA | TLX 2.4 | 01.2016-12.2016 | |
| HONDA | CR-V 2.4 | 01.2015-12.2015 | |
| HONDA | CR-V 2.4 | 01.2016-12.2016 |
Reference Information
90-29-5874 125.585.135 31100-5X6-J01 CSP47 104211-3471 104211-3470 210-0809 UD14843AVideo/Publications
104211-3470 104211-3471 125.585.135 210-0809 31100-5X6-J01 90-29-5874 CSP47 UD14843AAdd Your Number
