Associated Numbers
0001108222 0001108223 0061511001 101414V 114178 17966N 17966R 17966R-LT 20401754OE 22.1414 25-4042 3209 6010457 68011829AB 8021300 88212671 A0061511001 AEY2370 CS1414 CST10457GS LRS02370 SS537 AUTOELECTRO BOSCHList CARGO CASCO CEVAM CHRYSLER 254042 ELSTOCK FRIESEN HC PARTS LAUBER LUCAS MERCEDES POWERMAX REAL SANDO SOVEREIGN WAI / TRANSPO 17966RLT Bosch References: Arrowhead SBO0173 0001115006 0986021300 2130 SR0817X Chrysler Delco DRT1300 Lester 17966 Lucas LRS01585 LRS2370 Mercedes 0051510101 006151100180 1121510101 A0051510101 A006151100180 PIC Picture ID 120384 120384A Remy Light Duty 16021 Youtech/PartRef 422609 Wilson 91157266 Substitutes: J N 41024275 B0001108222 J& BSR0817X 61511001 Benz ruil 11021300 EuroTec Cargo Elstock 414466 4865SP Spidan 550527102 PSH 8021300F Friesen 921300 EDR A21300 ATL HCS1414 OSM11924 Optimum STR1497sa Electrolog STRH100 Unipoint bxs0159 show 0001108222RT RNL Mercedes-Benz 12130340 AES 1986S00696 Karmann 438265 Valeo BOS0001108222 Wood Auto RNL2130 STR50726 WOOSTR50726Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 246 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | 240 2.6 | (C209)[M112.912] | 06.2002-05.2009 |
| MERCEDES BENZ | C 230 2.5 | (203)[M272.920] | 01.2005- |
| MERCEDES BENZ | C 230 2.5 | (203)[M272.920] | 01.2005-05.2008 |
| MERCEDES BENZ | C 230 2.5 | (204)[M272.921] | 01.2007- |
| MERCEDES BENZ | C 230 2.5 | (S204)[M272.921] | 08.2007- |
| MERCEDES BENZ | C 230 2.5 4-Matic | (W204)[M272.911] | 07.2007- |
| MERCEDES BENZ | C 280 3.0 | (203)[M272.940] | 01.2005- |
| MERCEDES BENZ | C 280 3.0 | (204)[M272.947] | 01.2007- |
| MERCEDES BENZ | C 280 3.0 | (S204)[M272.947] | 08.2007- |
| MERCEDES BENZ | C 280 3.0 4-Matic | (203)[M272.941] | 01.2005- |
| MERCEDES BENZ | C 280 3.0 4-Matic | (W204)[M272.947] | 07.2007- |
| MERCEDES BENZ | C 350 3.5 | (204)[M272.962] | 01.2007- |
| MERCEDES BENZ | C 350 3.5 | (S204)[M272.961] | 08.2007- |
| MERCEDES BENZ | C 350 3.5 4-Matic | (W204)[M272.971] | 07.2007- |
| MERCEDES BENZ | C 350 3.5 CGi | (W204)[M272.982] | 09.2008- |
| MERCEDES BENZ | CL 500 5.5 | (216)[M273.961] | 06.2006- |
| MERCEDES BENZ | CLC 230 2.5 | [M272.920] | 05.2008-06.2011 |
| MERCEDES BENZ | CLK 280 3.0 | (209)[M272.940] | 01.2005- |
| MERCEDES BENZ | CLK 350 3.5 | (209)[M272.960] | 01.2005- |
| MERCEDES BENZ | CLK 500 5.5 | (209)[M273.965] | 06.2006- |
| MERCEDES BENZ | CLK 500 5.5 | (A209)[M273.967] | 06.2006- |
| MERCEDES BENZ | S 350 3.5 | (221)[M272.965] | 10.2005- |
| MERCEDES BENZ | S 350 3.5 4-Matic | (W221)[M272.965] | 02.2008- |
| MERCEDES BENZ | S 450 4.7 | (221)[M273.923] | 12.2005- |
| MERCEDES BENZ | S 450 4.7 4-Matic | (221)[M273.922] | 12.2005- |
| MERCEDES BENZ | S 500 5.5 | (221)[M273.961] | 10.2005- |
| MERCEDES BENZ | S 500 5.5 4-Matic | (221)[M273.961] | 10.2005- |
| MERCEDES BENZ | S 600 5.5 | (221)[M275.953] | 12.2005- |
| MERCEDES BENZ | S 65 AMG 6.0 | (221)[M275.982] | 12.2005- |
| MERCEDES BENZ | SL 350 3.5 | (230)[M272.966] | 03.2006- |
| MERCEDES BENZ | SL 500 5.5 | (230)[M273.965] | 03.2006- |
| MERCEDES BENZ | SLK 280 3.0 | (171)[M272.942] | 01.2005- |
| MERCEDES BENZ | Sprinter 224 3.5 | (906)[M272.979] | 06.2006- |
| MERCEDES BENZ | Sprinter 324 3.5 | (906)[M272.979] | 06.2006- |
| MERCEDES BENZ | Sprinter 424 3.5 | (906)[M272.979] | 06.2006- |
| MERCEDES BENZ | Sprinter 524 3.5 | (906)[M272.979] | 06.2006- |
Reference Information
5010515 STR1497 CS1414 STM703 A0061511001 6151620180 51510101 101414V LRS2370 A005151010180 61516201 22.1414 6010457 0001108223 CST10457GS 0001108222 1108223 1108222 A0061516201 6151100180 A006151620180 17966R-LT A006151440180 414466 61511001 25-4042 AEY2370 3209 S0389 8021300 SS537 20401754OE 61514401 114178 68011829AB 5151010180 STRF024 17966R 17966N A006151100180 88212671 6151440180 LRS02370 S12BH0676A2 68012448AC 68012448AB A0061514401 A0051510101 331192Video/Publications
0001108222 0001108223 0061511001 101414V 114178 17966N 17966R 17966R-LT 20401754OE 22.1414 25-4042 3209 6010457 68011829AB 8021300 88212671 A0061511001 AEY2370 CS1414 CST10457GS LRS02370 LRS2370 SS537 STRF024 S0389Add Your Number
