Associated Numbers
UD13599A ASPLList
12986 DELCO
A80535 DIXIE
J5113077 HERTH+BUSS
ALM5693 KRAUF
N3R118300 MAZDA
A003TG5691 MITSUBISHI
A3TG5691 MITSUBISHI
UNIT BOM 2035062A WAI / TRANSPO
90273382 WILSON
Arrowhead A3TG5691
Lester 11329
Mazda N3R118300
Mitsubishi A003TG5691
12986 90-27-3382 A-80535 A003TG5691 A3TG5691 ALM5693 J5113077 N3R1-18-300 UD13599A UNIT BOM 203-5062A anj558 anj558GQ
Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 12.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 5 qty |
| Length (L.1) | 162 mm |
| Mount Inside Length or Pad Mount C-C (C) | 66.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_3310 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 36.5 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | RX-8 1.3 | [13B-MSP] | 01.2009-12.2011 |
Reference Information
J5113077 BOM N3R1-18-300 UNIT 90-27-3382 CAL35411GS ALM5693 UD13599A 203-5062A 2035411.1 A003TG5691 A-80535 20137114OE 12986 A3TG5691Video/Publications
12986 90-27-3382 A-80535 A003TG5691 A3TG5691 ALM5693 J5113077 N3R1-18-300 UD13599A UNIT BOM 203-5062AAdd Your Number
