- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
UD15412A ASPL
0986UR6315 BOSCH
22949467 CHEVROLET
1042106870 DENSO
A80650 DIXIE
29010702 ROBERT'S
14009N WAI / TRANSPO
90295893 WILSON
Denso 1042106870, 1042106871
General Motors 22949467
Lester 14009
PIC Picture ID 2906384
1042106870 DENSO (NIPPON DENSO)
1042106871 DENSO (NIPPON DENSO)
1042106872 DENSO (NIPPON DENSO)
22949467 GMC
84332808 GMC
84542723 GMC
14009 LESTER
90295893 WILSON
0986UR6315 104210-6870 14009N 22949467 290-10702 90-29-5893 A-80650 UD15412A
Specifications
| Amp | 170 A |
| Bottom Mounting Foot Width (B) | 50.5 mm |
| Diameter (D.1) | 12 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 6 qty |
| Length (L.1) | 172 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 59 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 73 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | Escalade 6.2 | 01.2015-12.2015 | |
| CADILLAC | Escalade ESV 6.2 | 01.2015-12.2015 | |
| CHEVROLET | Silverado 1500 4.3 | 01.2014-12.2014 | |
| CHEVROLET | Silverado 1500 4.3 | 01.2015-12.2015 | |
| CHEVROLET | Silverado 1500 5.3 | 01.2014-12.2014 | |
| CHEVROLET | Silverado 1500 5.3 | 01.2015-12.2015 | |
| CHEVROLET | Silverado 1500 6.2 | 01.2014-12.2014 | |
| CHEVROLET | Silverado 1500 6.2 | 01.2015-12.2015 | |
| CHEVROLET | Suburban 1500 5.3 | 01.2014-12.2014 | |
| CHEVROLET | Suburban 5.3 | 01.2014-12.2014 | |
| CHEVROLET | Suburban 5.3 | 01.2015-12.2015 | |
| CHEVROLET | Tahoe 5.3 | 01.2015-12.2015 | |
| GMC | Sierra 1500 4.3 | 01.2014-12.2014 | |
| GMC | Sierra 1500 4.3 | 01.2015-12.2015 | |
| GMC | Sierra 1500 5.3 | 01.2014-12.2014 | |
| GMC | Sierra 1500 5.3 | 01.2015-12.2015 | |
| GMC | Sierra 1500 6.2 | 01.2014-12.2014 | |
| GMC | Sierra 1500 6.2 | 01.2015-12.2015 | |
| GMC | Sierra 5.3 | 01.2014-12.2014 | |
| GMC | Sierra 5.3 | 01.2015-12.2015 | |
| GMC | Sierra 6.2 | 01.2014-12.2014 | |
| GMC | Sierra 6.2 | 01.2015-12.2015 | |
| GMC | Yukon 5.3 | 01.2015-12.2015 | |
| GMC | Yukon 6.2 | 01.2015-12.2015 | |
| GMC | Yukon XL 5.3 | 01.2015-12.2015 | |
| GMC | Yukon XL 6.2 | 01.2015-12.2015 |
Reference Information
00986CR6315 84143540 A-80650 14009N 290-10702 00986UR6315 0986CR6315 UD15412A 104210-6870 0AL8869X 0986UR6315 22949467 AL8869X 90-29-5893Video/Publications
0986UR6315 104210-6870 14009N 22949467 290-10702 90-29-5893 A-80650 UD15412AAdd Your Number
