Associated Numbers
063280055010 0986023910 113314 12056 17806N 17806R 190.558.092 201224 201224D 201233 201233D 20452101BN 20452101OE 20510216 220926 228000-8550 25-3094 28100-21020 28100-21021 28100-21030 28100-21031 28100-21050 428000-7750 6044101 63280055 8212325 AES2216 CST44101 CST44101AS CST44101ES CST44101GS CST44101OS CST44101RS DENDSN934 DRS3866 DS4976 DSN934 J5212104 JS1224 LRT00216 MSN8055 SG0260 SS062 SS598 STM1224 STN1224 STR70291 S6036 S6256S S6036
2280008541 2280008542 2810021020 2810021021
AES2216 AUTOELECTRO
0986023910 BOSCH
113314 CARGO
CST44101 CASCO
CST44101AS CASCO
CST44101ES CASCO
CST44101GS CASCO
CST44101OS CASCO
CST44101RS CASCO
DRS3866 DELCO
DS4976 DELCO
2280008550 DENSOList
4280007750 DENSOList
DSN934 DENSO
12056 EAI
253094 ELSTOCK
220926 ERA
SG0260 GHIBAUDI
JS1224 HC PARTS
J5212104 HERTH+BUSS
STM1224 KRAUF
STN1224 KRAUF
201224 KUHNER
201224D KUHNER
201233 KUHNER
201233D KUHNER
LRT00216 LUCAS
063280055010 MAGNETI MARELLI
63280055 MAGNETI MARELLI
MSN8055 MAGNETI MARELLI
8212325 POWERMAX
20510216 PRESTOLITE
190.558.092 PSH
20452101BN REAL
20452101OE REAL
6044101 SANDO
SS062 SOVEREIGN
SS598 SOVEREIGN
2810021020 TOYOTAList
2810021021 TOYOTA
2810021030 TOYOTAList
2810021031 TOYOTA
2810021050 TOYOTA
17806N WAI / TRANSPO
17806R WAI / TRANSPO
DENDSN934 WOODAUTO
STR70291 WOODAUTO
snj259 dxs570
Bosch SR3280X
Denso 2800279
Wilson 91295487
References:
Arrowhead SND0353
Bosch SR3280X
Delco 17730
Denso 2280008550, 2800279
Lester 17806
PIC Picture ID 190463
Toyota 2810021030
Wilson 91295487
J&N 41052271
Denso 2280008550
References:
J&N 41052271
Bosch SR3280X
Delco 19135594
Denso 2280008550, 2800279
Lester 17806
PIC Picture ID 190463
Toyota 2810021030
Denso 228000855
Substitutes:
J&N 41052271
Bosch SR3280X
Denso 2800279
Remy Light Duty 17730
Wilson 91295487
References:
Arrowhead SND0353
Denso 228000855
Wilson 91295487
0986020541 Bosch ruil
0986023910 Bosch ruil
11040635 EuroTec
11040694 EuroTec
11040702 EuroTec
12056 EAI
17806N WAI
190558092 PSH
190965092 PSH
20510216 Prestolite
2280008540 Denso
2280008542 Denso
2280008550 Denso
252422 Elstock
281000M051 Toyota
2810021020 Toyota
2810021021 Toyota
2810021022 Toyota
2810021030 Toyota
2810021031 Toyota
2810021032 Toyota
2810021050 Toyota
4280007750 Denso
458320 Valeo
4701SP Spidan
91295487 Wilson
91295496 Wilson
9709 CEVAM
ATS376 ATK
DRS3866 Remy
DSN934 Denso
F042S00207 Bosch
HJS1224 HC
HJS1233 HC
J5212093 Nipparts
J5212094 Nipparts
JS1224 HC
JS1233 HC
LRS01479 Lucas
STR6164sa Electrolog
STR8268 Unipoint
STR8280 Unipoint
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 211 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 13 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Yaris 1.3 | [2NZ-FE] | 11.1995-10.2005 |
| TOYOTA | Yaris 1.5 | [1NZ-FE] | 01.2003-11.2005 |
| TOYOTA | Yaris 1.5 | [1NZ-FE] | 03.2000-07.2005 |
| TOYOTA | Yaris 1.5 | [1NZ-FE] | 04.2001-09.2005 |
| TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 08.1999-10.2002 |
| TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 11.2002-09.2005 |
| TOYOTA | Yaris Verso 1.5 | [1NZ-FE] | 03.2000-09.2005 |
Reference Information
DS4976 JS1224 3T356 SS598 201233D 28100-21050 003-T356 STRL265 6044101 228000-8550 63280055010 LRT00216 ANM16086X CST44101ES 201224D SG0260 5040183 28100-21021 SS062 28100-21022 28100-21020 63280055 281002102 190.558.092 MAV5970 8212325 113314 17806R MSN8055 17806N AES2216 000986023910 DENDSN934 MTT356 STR6164 CST44101AS DRS3866 28100-21030 428000-7750 S12DE0226 28100-21031 2810021040 12056 S6036 CST44101RS 20510216 MAV461090 CGB-28540 220926 20452101BN DSN934 CST44101OS 28100-0M051 220486 201224 986023910 CST44101 CST44101GS STN1224 J5212104 201233 25-3094 STR70291 20452101OE S12DE0226A2 STM1224Video/Publications
003-T356 063280055010 0986023910 113314 12056 17806N 17806R 190.558.092 201224 201224D 201233 201233D 20452101BN 20452101OE 20510216 220926 228000-8550 25-3094 28100-21020 28100-21021 28100-21030 28100-21031 28100-21050 3T356 428000-7750 6044101 8212325 AES2216 CGB-28540 CST44101 CST44101AS CST44101ES CST44101GS CST44101OS CST44101RS DENDSN934 DRS3866 DS4976 J5212104 JS1224 LRT00216 MAV461090 MAV5970 MSN8055 MTT356 SG0260 SS062 SS598 STM1224 STN1224 STR70291 STRL265 S6036 220486Add Your Number
