- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
Associated Numbers
114137 120.570.092 17958N 17958R 31200-RNA-A50 31200-RNA-A51 91-26-2061 91-26-2061N J5214057 RNA50 S-80316 SM710-01 STR75464 STU4137 UD03383S CARGO S80316 DIXIE HERTH+BUSS 31200RNAA50 HONDA 31200RNAA51 KRAUF SM71001 MITSUBAList PSH WAI / TRANSPO 91262061 WILSON 91262061N WOODAUTO mxs816 702847 snj609 120570092 17958 Lester 191186 PIC 22816MT Honda 910838 EDR Wilson DRS0838 Remy LRS02596 Lucas Mitsuba Bosch SR1339X References: Arrowhead SMU0435 J N 41054130 Picture ID JANNCO 41054130R BSR1339X J& J&NSpecifications
Kilowatt | 1.20 kW |
Length (L.1) | 244 mm |
Mount Hole Center - Center (O.1) | 125 mm |
Mount Hole Diameter (C.1) | 13.50 mm |
Mount Hole Diameter (C.2) | 10.50 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
OEM Product | No |
Pinion at Rest (B) | 34 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | MITSUBA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Civic 1.8 | [R18A1] | 09.2005-02.2012 |
HONDA | Civic 1.8 | [R18A2] | 09.2005-02.2012 |
Alternatives >>>
S9038- Alternative option
Reference Information
114137 | CARGO |
120.570.092 | PSH |
17958N | WAI / TRANSPO |
17958R | WAI / TRANSPO |
20467521BN | REAL |
31067 | RELIANCE |
31200-RNA-A50 | HONDA |
31200-RNA-A51 | HONDA |
6033125.0 | SANDO |
61067 | RELIANCE |
91-26-2061 | WILSON |
91-26-2061N | WILSON |
CST33125AS | CASCO |
F032114137 | CARGO |
J5214057 | HERTH+BUSS |
MAV351250A | SIOM |
RNA50 | HONDA |
S-80316 | DIXIE |
SM710-01 | MITSUBA |
STR5976 | ELECTROLOG |
STR75464 | WOODAUTO |
STU4137 | KRAUF |
STX200595 | STARDAX |
UD03383S | AS-PL |
Video/Publications
S9038SView your shopping basket or Browse other items in Starter Motors.
