Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 486.02 including GST
NZ$ 422.63 excluding GST
or four payments of $121.51
with
Learn More
each
A0056
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0124325016Associated Numbers
0124315007 0124325016 037903025G 037903025K 037903025N 037903025R 0986044390 11.1567 112412 113870 2015375 20179573OE 21480N 22995N 2542259 2542279 2542279C 28-3903 28-3917 301567RI 301568RI 32437398 4063 437398 437402 439439 439443 542259 56856 89212661 8EL737833-001 9044390 9212661 AEA4279 AEA4280 ALT14148 ALT14238 CA1567IR CAL15375GS DRA3805 IA1305 LRA01997 LRB00479 SA308 SA310 SA629 SB010 SG8B017 SG9B019Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A2 1.4 | [AUA] | 09.1999-06.2001 |
| SEAT | Ibiza 1.4 16V | [AUB] | 02.2002- |
| SEAT | Ibiza 1.4 16V | [BBY] | 02.2002- |
| SEAT | Ibiza 1.4 16V | [BBZ] | 02.2002- |
| SKODA | Fabia 1.4 16V | [AUA] | 09.1999-09.2001 |
| SKODA | Fabia 1.4 16V | [AUB] | 09.1999-09.2001 |
| SKODA | Fabia 1.4 16V | [BBY] | 09.2000-05.2004 |
| SKODA | Fabia 1.4 16V | [BBZ] | 09.2000-09.2001 |
| SKODA | Fabia 1.4 16V | [BKY] | 09.2000-09.2001 |
Reference Information
| 0124315007 | BOSCH |
| 0124325016 | BOSCH |
| 037903025G | VW |
| 037903025K | VW |
| 037903025N | VW |
| 037903025R | VW |
| 037903025RX | VW |
| 037903026B | VW |
| 037903026BX | VW |
| 06B903018M | VW |
| 0986044390 | BOSCH |
| 11.1567 | LAUBER |
| 112412 | CARGO |
| 113870 | CARGO |
| 2015375 | SANDO |
| 20179573OE | REAL |
| 209282 | ERA |
| 210671 | ERA |
| 21480N | WAI / TRANSPO |
| 22995N | WAI / TRANSPO |
| 2542259 | VALEO |
| 2542279 | VALEO |
| 2542279C | VALEO |
| 28-3903 | ELSTOCK |
| 301567RI | KUHNER |
| 301568RI | KUHNER |
| 310902 | RHIAG |
| 32437398 | HERTH+BUSS |
| 37903025G | VW |
| 37903025K | VW |
| 37903025N | VW |
| 37903025R | VW |
| 37903025RX | VW |
| 37903026B | VW |
| 37903026BX | VW |
| 4063 | CEVAM |
| 437398 | VALEO |
| 437402 | VALEO |
| 439439 | VALEO |
| 439443 | VALEO |
| 441715 | LOGISTIK |
| 542259 | VALEO |
| 56856 | EAI |
| 89212661 | POWERMAX |
| 8EL737833-001 | HELLA |
| 9044390 | FRIESEN |
| 9212661 | POWERMAX |
| A0056 | AS-PL |
| A12BH1164A2 | SIDAT |
| AEA4279 | AUTOELECTRO |
| AEA4280 | AUTOELECTRO |
| ALT00474 | ELECTROLOG |
| ALT00675 | ELECTROLOG |
| ALT10082 | ELECTROLOG |
| ALT122810 | SIOM |
| ALT1316 | ELECTROLOG |
| ALT14148 | WOODAUTO |
| ALT14238 | WOODAUTO |
| ALT173160 | SIOM |
| ALT173750 | SIOM |
| ALTF043 | 3EFFE |
| ALTS811 | 3EFFE |
| ALTW296 | 3EFFE |
| ANM36025X | ANDEL |
| CA1567IR | HC PARTS |
| CAL15375GS | CASCO |
| CGB-83903 | AINDE |
| DRA3805 | DELCO |
| F032112412 | CARGO |
| F032113870 | CARGO |
| IA1305 | ISKRA / LETRIKA |
| LRA01997 | LUCAS |
| LRA1997 | LUCAS |
| MG 367 | MAHLE |
| PRAS811 | 3EFFE |
| SA308 | SOVEREIGN |
| SA310 | SOVEREIGN |
| SA629 | SOVEREIGN |
| SB010 | SOVEREIGN |
| SG8B017 | VALEO |
| SG9B019 | VALEO |
| STX100413 | STARDAX |
| STX100413R | STARDAX |
| STX100666 | STARDAX |
Video/Publications
