A0087 - Brand new AS-PL Alternator

Name: Brand new AS-PL Alternator
Brand: AS-PL
SKU: A0087
Price: 363.83 NZD
Availability: BackOrder

Brand new AS-PL Alternator

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

BOSCH

Price:

NZ$ 363.83 including GST

NZ$ 316.37 excluding GST

or four payments of $90.96 with
Learn More

UOM:

each

Product Code:

A0087

Quantity In Stock Nationally:

No stock in NZ currently

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Information
Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

0120469527

0120469527 0120469562 0120469592 0120469761 0120469891 0120469983 0986033100 0986036920 111146 18.0240 18.0240M 20101736BN 20101736OE 2010637 2052 20977N 30240RI 436422 48-0995 48-1893 51.26101-7156 51.26101-7190 75575 857475 859020 89212552 8EL725663-001 9936920 AEA9178 ALT10416 CA240IR CAL10637AS CAL10637GS DRA3100 DRA6920 EAA-221633 LRA00978 LRB00102

Amp	55 A
Bottom Mounting Foot Width (B)	80 mm
Diameter (D.1)	10.50 mm
Diameter (D.2)	10.50 mm
Diameter (D.3)	10.50 mm
Length (L.1)	204 mm
OEM Product	No
Plug Code	PL_9105
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	2 qty
Pulley Groove Width (W.1)	9.50 mm
Pulley Outside Diameter (O.D.1)	47 mm
Pulley Outside Diameter (O.D.2)	69 mm
Pulley to Mount Distance (A)	118.50 mm
Pulley Type	Solid
Unit Type	BOSCH
Voltage	24 V

Make	Model	Type	Year
DAF	95.310 11.6	[WS225]	09.1987-
DAF	95.330 11.6	[WS259]	09.1987-
DAF	95.350 11.6	[WS259]	09.1987-04.1997
DAF	95.360 11.6	[WS268M]	03.1993-04.1997
DAF	95.360 11.6	[WS268][WS268G][WS268L][WS268M]	08.1990-04.1997
DAF	95.380 11.6	[WS282]	09.1987-
DAF	95.400 11.6	[WS295][WS295G][WS295L]	08.1990-
DAF	95.400 11.6	[WS295][WS295G][WS295L][WS295M]	08.1990-04.1997
DAF	95.430 11.6	[WS315][WS315L][WS315M]	02.1992-
DAF	F 1200 5.8	[DD575]	05.1977-12.1981
DAF	F 1300 6.2	[DT615]	07.1978-02.1990
DAF	F 1305 6.2	[DT615]	07.1978-02.1990
DAF	F 1400 5.8	[DD575]	02.1972-12.1981
DAF	F 1500 6.2	[DF615][DT615]	07.1978-08.1991
DAF	F 1600 6.2	[DF615]	01.1970-08.1991
DAF	F 1800 6.2	[DT615]	05.1977-08.1991
DAF	F 2100 6.2	[DF615]	07.1978-09.1986
DAF	F 2100 8.3	[DH825]	07.1978-09.1986
DAF	F 2100 8.3	[DHR825]	07.1978-08.1991
DAF	F 2103 8.3	[DH825]	07.1978-08.1991
DAF	F 2103 8.3	[DHT825]	07.1981-09.1986
DAF	F 2103 8.3	[DHTD825]	06.1986-08.1991
DAF	F 2105 6.2	[DF615]	07.1978-08.1991
DAF	F 2105 8.3	[DH825]	07.1978-08.1991
DAF	F 2105 8.3	[DHR825][DHTD825]	07.1981-09.1986
DAF	F 2105 8.3	[DHT825]	06.1986-08.1991
DAF	F 2105 8.3	[DHTD825]	07.1978-09.1986
DAF	F 2300 8.3	[DHR825][DHU825]	07.1978-12.1981
DAF	F 2300 8.3	[DHT825]	11.1981-08.1991
DAF	F 2300 8.3	[DHTD825]	06.1986-08.1991
DAF	F 2300 8.3	[DHU825]	07.1978-12.1983
DAF	F 2305 8.3	[DH825]	07.1978-12.1981
DAF	F 2305 8.3	[DHR825]	07.1978-08.1991
DAF	F 2305 8.3	[DHT825]	07.1978-09.1986
DAF	F 2305 8.3	[DHU825]	07.1978-12.1983
DAF	F 2335 8.3	[DHT825]	07.1978-08.1991
DAF	F 2500 8.3	[DHS825]	02.1982-08.1991
DAF	F 2503 8.3	[DHS825]	02.1982-09.1986
DAF	F 2505 8.3	[DHS825]	02.1982-08.1991
DAF	F 2505 8.3	[DHS825]	06.1986-08.1991
DAF	F 2525 8.3	[DHS825]	02.1982-08.1991
DAF	F 2535 8.3	[DHS825]	02.1982-08.1991
DAF	F 2800 11.6	[DKA1160]	01.1974-09.1991
DAF	F 2800 11.6	[DKS1160E]	05.1977-09.1991
DAF	F 2800 11.6	[DKT1160]	05.1977-09.1991
DAF	F 2800 11.6	[DKTD1160]	01.1974-09.1991
DAF	F 2803 11.6	[DKS1160]	05.1977-09.1991
DAF	F 2803 11.6	[DKS1160E]	01.1980-07.1990
DAF	F 2803 11.6	[DKTD1160]	01.1974-09.1991
DAF	F 2804 11.6	[DKS1160E][DKT1160]	01.1980-09.1986
DAF	F 2805 11.6	[DKS1160][DKTD1160]	05.1977-09.1991
DAF	F 2805 11.6	[DKS1160E]	01.1974-09.1991
DAF	F 2815 11.6	[DKS1160]	05.1977-12.1981
DAF	F 2825 11.6	[DKTD1160]	01.1974-09.1991
DAF	F 2825 11.6	[DKV1160]	05.1983-09.1991
DAF	F 3300 11.6	[DKX1160]	06.1981-09.1986
DAF	F 3300 11.6	[DKX1160ATI]	06.1985-09.1991
DAF	F 3303 11.6	[DKX1160]	06.1981-09.1986
DAF	F 3303 11.6	[DKX1160ATI]	06.1985-09.1991
DAF	F 3305 11.6	[DKX1160]	06.1981-09.1991
DAF	F 3325 11.6	[DKX1160]	06.1981-09.1986
DAF	F 3325 11.6	[DKX1160ATI][DKX1160]	06.1985-09.1991
DAF	F 3600 11.6	[DKZ1160ATI]	06.1985-09.1991
DAF	F 3603 11.6	[DKZ1160ATI][DKZE1160]	06.1985-09.1991
DAF	F 3605 11.6	[DKZ1160ATI][DKZE1160]	06.1985-09.1991
DAF	F 3625 11.6	[DKZ1160ATI]	06.1985-09.1991
DAF	N 2826 11.6	[DKS1160]	01.1981-09.1991
DAF	N 3326 11.6	[DKX1160]	01.1981-09.1991
FORD	0915 5.9	[150/6CA-Dover]	01.1982-01.1996
FORD	1115 6.0	[150/6CA-Dover]	01.1982-01.1996
MAN	12.152 6.9	(M90)[D0826F01](M90)[D0826F02]	12.1988-05.1994
MAN	12.232 6.9	(M90)[D0826LF02](M90)[D0826LF06](M90)[D0826LF08]	08.1988-06.1996
MAN	14.152 6.9	(M90)[D0826F01]	12.1988-05.1994
MAN	14.192 6.6	(M90)[D0826TF]	08.1988-06.1990
MAN	14.232 6.9	(M90)[D0826LF02](M90)[D0826LF06](M90)[D0826LF08]	08.1988-06.1996
MAN	17.192 6.6	(M90)[D0826TF]	02.1989-06.1990
MAN	17.232 6.9	(M90)[D0826LF02](M90)[D0826LF06](M90)[D0826LF08]	05.1990-01.1991
MAN	17.232 6.9	(M90)[D0826LF/217/Silent]	05.1990-01.1991
MAN	8.170 5.7	(G90)[D0226MCFO/170]	02.1989-10.1993
MAN	9.170 5.7	(G90)[D0226MCFO/170]	02.1989-10.1993

0120469527	BOSCH
0120469562	BOSCH
0120469592	BOSCH
0120469761	BOSCH
0120469891	BOSCH
0120469983	BOSCH
0120488273	BOSCH
0120489684	BOSCH
0636247R	DAF
0986033100	BOSCH
0986036920	BOSCH
111146	CARGO
1516537R	DAF
1596677	FORD
1612497	FORD
18.0240	LAUBER
18.0240M	LAUBER
20101736BN	REAL
20101736OE	REAL
2010637	SANDO
2052	CEVAM
20977N	WAI / TRANSPO
2871686	PERKINS
297297	DAF
30240RI	KUHNER
3276269	CUMMINS
371963	SCANIA
371963	DAF
4000663M91	HANOMAG
436422	VALEO
440386	LOGISTIK
440387	LOGISTIK
440481	LOGISTIK
4630801130	SAURER
48-0995	ELSTOCK
48-1893	ELSTOCK
51.26101-7156	MAN
51.26101-7190	MAN
51261017205	MAN
51.26101-9190	MAN
6143717	FORD
636247	DAF
659452	DAF
75575	EAI
81DB10300BB	FORD
81DB10346BB	FORD
82DB10346BA	FORD
857475	PRESTOLITE
859020	PRESTOLITE
890667R	DAF
890967	DAF
89212552	POWERMAX
8EL725663-001	HELLA
9936920	FRIESEN
A0087	AS-PL
A24BH0117A2	SIDAT
AEA9178	AUTOELECTRO
ALT10416	WOODAUTO
ALT1251	ELECTROLOG
ALT126370	SIOM
ALT126370A	SIOM
ALTL256	3EFFE
ALTL256HQ	3EFFE
ALTW148	3EFFE
ANM39140X	ANDEL
CA240IR	HC PARTS
CAL10637AS	CASCO
CAL10637GS	CASCO
CGB-13100	AINDE
CGB-80995	AINDE
DRA3100	DELCO
DRA6920	DELCO
F032111146	CARGO
LRA00978	LUCAS
LRA978	LUCAS
LRB00102	LUCAS
LRB102	LUCAS
PRAL256	3EFFE
PRAL256HQ	3EFFE
PTC-3054	POWER TRUCK
R81DB10346BA	FORD
R81DB10346BB	FORD
R81DB10346EA	FORD

A0087
