Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 317.83 including GST
NZ$ 276.37 excluding GST
or four payments of $79.46
with
Learn More
each
A0102
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0120489731Associated Numbers
0120489731 0986031320 11.0368 110117 12031N 12149N 18.3003 2009 20130134 2084 2960120 30368RI 436420 48-0780 586.002.035 586.003.035 75602 861001 8EL725772-001 9AR6012 ALT20020 CA368IR DRA1320 EAA-221551 LRA02423Specifications
| Amp | 35 A |
| Bottom Mounting Foot Width (B) | 56 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Length (L.1) | 203 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 2 qty |
| Pulley Groove Width (W.1) | 9.50 mm |
| Pulley Outside Diameter (O.D.1) | 49 mm |
| Pulley Outside Diameter (O.D.2) | 69 mm |
| Pulley to Mount Distance (A) | 93 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | P/PA 190-25 12.8 | 01.1986-09.1990 | |
| IVECO | P/PA 190-25 12.8 | 07.1983-12.1986 | |
| IVECO | P/PA 190-25 12.8 | 07.1983-12.1987 | |
| IVECO | P/PA 260-25 12.8 | 03.1984-06.1986 | |
| IVECO | P/PA 260-25 12.8 | 12.1979-10.1985 | |
| MAN | 41.422 12.0 | 01.1990-12.1994 | |
| STEYR | 12 M 18 6.6 | 09.1986- |
Reference Information
| 0120489731 | BOSCH |
| 0986031320 | BOSCH |
| 110117 | CARGO |
| 11.0368 | LAUBER |
| 1172646 | IVECO |
| 1172649 | IVECO |
| 12031N | WAI / TRANSPO |
| 18.3003 | LAUBER |
| 2009 | CEVAM |
| 20130134 | PRESTOLITE |
| 2960120 | VALEO |
| 30368RI | KUHNER |
| 436420 | VALEO |
| 48-0780 | ELSTOCK |
| 586.002.035 | PSH |
| 586.003.035 | PSH |
| 75602 | EAI |
| 8EL725772-001 | HELLA |
| 9AR6012 | MOTOROLA |
| ALT20020 | WOODAUTO |
| ALTL260 | 3EFFE |
| ALTL260V | 3EFFE |
| CA368IR | HC PARTS |
| CGB-11320 | AINDE |
| DRA1320 | DELCO |
| F032110117 | CARGO |
| LRA02423 | LUCAS |
| LRA2423 | LUCAS |
| PRAL260 | 3EFFE |
