Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 547.89 including GST
NZ$ 476.43 excluding GST
or four payments of $136.97
with
Learn More
each
A0124
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
0124555008 0518064 0578064 0986046580 114028 1442788 1475570 18.1851 18.3029 20101836OE 2010638 23833N 2437 301851RI 301851RIB 48-4951 571613 860805GB 861275GB 89213532 8EL738211-111 9946580 ALT10343 CA1851IR CAL10638GS DRB6580 EAA-221273 LRA02833Specifications
| Amp | 80 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Diameter (D.4) | 10 mm |
| Length (L.1) | 208 mm |
| Mount Inside Length or Pad Mount C-C (C) | 36 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 85 mm |
| Pad mount thickness (E.2) | 85 mm |
| Plug Code | PL_5003 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 72 mm |
| Pulley to Mount Distance (A) | 22 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SCANIA | K114 10.6 | [DC..] | 08.1997- |
| SCANIA | P 230 8.9 | [DC9.13] | 09.2004-09.2006 |
| SCANIA | P 230 8.9 | [DC9.16] | 09.2004- |
| SCANIA | P 270 9.0 | [DC9.12] | 09.2004-09.2006 |
| SCANIA | P 310 8.9 | [DC9.11] | 09.2004-09.2006 |
| SCANIA | P 310 8.9 | [DC9.18] | 09.2004- |
| SCANIA | P 340 10.6 | [DC11.08] | 09.2004-09.2006 |
| SCANIA | P 380 10.6 | [DC11.09] | 09.2004-09.2006 |
| SCANIA | P 420 11.7 | [DC12.14] | 09.2004-09.2006 |
| SCANIA | P 420 11.7 | [DC12.15][DT12.12] | 09.2004- |
| SCANIA | R 340 10.6 | [DC11.08] | 03.2004-09.2006 |
| SCANIA | R 380 10.6 | [DC11.09] | 03.2004-09.2006 |
| SCANIA | R 420 11.7 | [DC12.14] | 03.2004-09.2006 |
| SCANIA | R 420 11.7 | [DT12.11] | 03.2004- |
| SCANIA | R 470 11.7 | [DT12.06] | 03.2004- |
| SCANIA | R 500 15.6 | [DC16.04] | 03.2004-09.2006 |
| SCANIA | R 580 15.6 | [DC16.03] | 03.2004-09.2006 |
| SCANIA | R 620 15.6 | [DC16.08] | 09.2005- |
| SCANIA | T 470 11.7 | [DT12.06] | 09.2004-10.2005 |
Reference Information
| 0124555008 | BOSCH |
| 0124555034 | BOSCH |
| 0518064 | SCANIA |
| 0578064 | SCANIA |
| 063535550080 | MAGNETI MARELLI |
| 0986046580 | BOSCH |
| 11.209.612 | ISKRA / LETRIKA |
| 114028 | CARGO |
| 115493 | CARGO |
| 1442788 | SCANIA |
| 1475570 | SCANIA |
| 1524011R | DAF |
| 1763035 | SCANIA |
| 18.1851 | LAUBER |
| 18.3029 | LAUBER |
| 19092043 | DELCO |
| 20101836OE | REAL |
| 2010638.0 | SANDO |
| 2010638.1 | SANDO |
| 2010638.5 | SANDO |
| 210592 | ERA |
| 23833N | WAI / TRANSPO |
| 301851RI | KUHNER |
| 301851RIB | KUHNER |
| 441797 | LOGISTIK |
| 48-4951 | ELSTOCK |
| 5610030 | MEAT & DORIA |
| 571613 | SCANIA |
| 72446574 | MAHLE |
| 861275GB | PRESTOLITE |
| 89213532 | POWERMAX |
| 8EL012584-061 | HELLA |
| 8EL738211-111 | HELLA |
| 9010607 | ZM |
| 9010608 | ZM |
| 916.503.080.014 | PSH |
| 916.503.080.210 | PSH |
| 916.503.080.215 | PSH |
| 943318511010 | MAGNETI MARELLI |
| 9946580 | FRIESEN |
| A0124 | AS-PL |
| A24BH0016 | SIDAT |
| A24BH0016AS | SIDAT |
| AAN5401 | ISKRA / LETRIKA |
| ALT10343 | WOODAUTO |
| ALT126380 | SIOM |
| ALT1318 | ELECTROLOG |
| ALT422 | ROLLCO |
| ALT79865 | ELECTROLOG |
| ALTW180 | 3EFFE |
| ANM48800X | ANDEL |
| CA1851IR | HC PARTS |
| CAL10638AS | CASCO |
| CAL10638GS | CASCO |
| CAL10638IS | CASCO |
| DB7690 | DELCO |
| DRB6580 | DELCO |
| F032114028 | CARGO |
| F032115493 | CARGO |
| IA9460 | ISKRA / LETRIKA |
| LRA02833 | LUCAS |
| LRA2833 | LUCAS |
| MG796 | MAHLE |
| PRAW180 | 3EFFE |
| PTC-3021 | POWER TRUCK |
| UD19546A | AS-PL |
| ZM9010607 | ZM |
| ZM9010608 | ZM |
