Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 387.81 including GST
NZ$ 337.23 excluding GST
or four payments of $96.95
with
Learn More
each
A0191
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0124325059Associated Numbers
0124325059 0124325146 0124415012 0986042760 11.1648 11.1648M 20101892BN 20101892OE 2010298 28-4570 301648RI 301648RIB 4026 46532669 46832123 46841966 57149 89212639 8EL737956-001 9042760 9212639 AEC1648 ALT10448 CA1648IR CAL10298AS CAL10298GS DRB2760 GA325059-A LRA02125 SB109Specifications
| Amp | 105 A |
| Bottom Mounting Foot Width (B) | 25 mm |
| Diameter (D.1) | 16.50 mm |
| Diameter (D.2) | 12.50 mm |
| Diameter (D.3) | 12.50 mm |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 71.50 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 58.50 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Brava 1.6 16V SX | [182A4.000] | 11.1998-10.2001 |
| FIAT | Doblo 1.6 | [182B6.000] | 09.2002- |
| FIAT | Doblo 1.6 i.e. 16V | [182B6.000] | 10.2001- |
| FIAT | Marea 1.6 16 V Bipower | [185A3.000] | 04.1999-09.2002 |
| FIAT | Marea 1.6 16 V Bipower | [186A4.000] | 04.1999-03.2002 |
| FIAT | Marea 1.6 i 16V | [182A4.000] | 03.1999- |
| FIAT | Multipla 1.6 16V | [182A4.000] | 04.1999- |
| FIAT | Multipla 1.6 16 V Bipower | [186A4.000] | 04.1999- |
| FIAT | Multipla 1.6 16V Bipower | [182B6.000] | 10.2001- |
| FIAT | Multipla 1.6 16V Blupower | [186A3.000] | 04.1999- |
| FIAT | Stilo 1.8 16V | [192A4.000] | 10.2001- |
| LANCIA | Lybra 1.6 16V | [182A4.000] | 07.1999-09.2000 |
| LANCIA | Lybra 1.6 16V | [182B6.000] | 09.2000- |
Reference Information
| 0124325059 | BOSCH |
| 0124325146 | BOSCH |
| 11.1648 | LAUBER |
| 11.1648M | LAUBER |
| 20101892BN | REAL |
| 20101892OE | REAL |
| 2010298 | SANDO |
| 209027 | ERA |
| 210287 | ERA |
| 23125R | WAI / TRANSPO |
| 28-4570 | ELSTOCK |
| 301648RI | KUHNER |
| 301648RIB | KUHNER |
| 310954 | RHIAG |
| 4026 | CEVAM |
| 441839 | LOGISTIK |
| 46532669 | ALFA ROMEO |
| 46813063 | FIAT |
| 46832123 | FIAT |
| 46841966 | FIAT |
| 57149 | EAI |
| 71785854 | FIAT |
| 89212639 | POWERMAX |
| 8EL737956-001 | HELLA |
| 9042760 | FRIESEN |
| 9212639 | POWERMAX |
| A0191 | AS-PL |
| A12BH0191A2 | SIDAT |
| AEC1648 | AUTOELECTRO |
| ALT1042 | ELECTROLOG |
| ALT10448 | WOODAUTO |
| ALT122980 | SIOM |
| ALT122980A | SIOM |
| ALTL223 | 3EFFE |
| ALTL223B | 3EFFE |
| ALTL223NE | 3EFFE |
| ANM44980X | ANDEL |
| CA1648IR | HC PARTS |
| CAL10298AS | CASCO |
| CAL10298GS | CASCO |
| DRB2760 | DELCO |
| GA325059-A | GPARTS |
| LRA02125 | LUCAS |
| LRA2125 | LUCAS |
| PRAL223 | 3EFFE |
| PRAL223B | 3EFFE |
| SB109 | SOVEREIGN |
| STX100291 | STARDAX |
| STX100291R | STARDAX |
Video/Publications
A0191View your shopping basket or Browse other items in Alternators.
