Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 436.69 including GST
NZ$ 379.73 excluding GST
or four payments of $109.17
with
Learn More
each
A0392
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
0123510048 0123510095 0124515087 0124515090 0986041280 113836 20101242BN 20101242OE 2010242 23035R 28-3953 301492RI 301492RIB 301688RI 301688RIB 32041280 4014 57145 60604238 60652354 60654127 60672342 60673305 8EL738036-001 CA1688IR CAL10242AS CAL10242GS LRA02035 UD02251ASpecifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 180 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 52.50 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 147 3.2 GTA | [932A.000] | 02.2003-03.2010 |
| ALFA ROMEO | 156 2.5 V6 24V | [AR32405] | 10.2000-05.2006 |
| ALFA ROMEO | 156 2.5 V6 24V | [AR32405] | 10.2000-09.2005 |
| ALFA ROMEO | 156 3.2 GTA | [932A.000] | 03.2002-05.2006 |
| ALFA ROMEO | 156 3.2 GTA | [932A.000] | 03.2002-09.2005 |
| ALFA ROMEO | 166 2.5 V6 24V | [AR34201] | 09.1998-10.2000 |
| ALFA ROMEO | 166 2.5 V6 24V | [AR36201] | 10.2000- |
| ALFA ROMEO | 166 3.0 V6 24V | [AR36101] | 10.2000- |
| ALFA ROMEO | 166 3.2 V6 24V | [936A.000] | 10.2003- |
| ALFA ROMEO | GTA 3.2 | [936A.000] | 11.2003- |
| ALFA ROMEO | GTV 3.2 V6 24V | [936A6.000] | 04.2003- |
| ALFA ROMEO | Spider 3.2 V6 24V | [936A6.000] | 04.2003-04.2005 |
Reference Information
| 0123510048 | BOSCH |
| 0123510095 | BOSCH |
| 0124515087 | BOSCH |
| 0124515090 | BOSCH |
| 0986041280 | MAGNETI MARELLI |
| 113836 | CARGO |
| 20101242BN | REAL |
| 20101242OE | REAL |
| 2010242 | SANDO |
| 209065 | ERA |
| 209069 | ERA |
| 23035R | WAI / TRANSPO |
| 28-3953 | ELSTOCK |
| 301492RI | KUHNER |
| 301492RIB | KUHNER |
| 301688RI | KUHNER |
| 301688RIB | KUHNER |
| 310989 | RHIAG |
| 32041280 | HERTH+BUSS |
| 4014 | CEVAM |
| 441639 | LOGISTIK |
| 441835 | LOGISTIK |
| 57145 | EAI |
| 60604238 | FIAT |
| 60652354 | FIAT |
| 60654127 | FIAT |
| 60655296 | FIAT |
| 60672342 | FIAT |
| 60673305 | FIAT |
| 60815587 | FIAT |
| 71723411 | FIAT |
| 71784319 | FIAT |
| 71784321 | FIAT |
| 8EL738036-001 | HELLA |
| A0392 | AS-PL |
| ALT1187 | ELECTROLOG |
| ALT122150 | SIOM |
| ALT122420 | SIOM |
| ALT1297 | ELECTROLOG |
| ALTL376 | 3EFFE |
| ALTL376B | 3EFFE |
| ALTL376RR | 3EFFE |
| ALTS606 | 3EFFE |
| CA1688IR | HC PARTS |
| CAL10242AS | CASCO |
| CAL10242GS | CASCO |
| F032113836 | CARGO |
| LRA02035 | LUCAS |
| LRA2035 | LUCAS |
| PRAL376 | 3EFFE |
| PRAL376B | 3EFFE |
| STX101519 | STARDAX |
| STX101570 | STARDAX |
| UD02251A | AS-PL |
Video/Publications
