Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 518.40 including GST
NZ$ 450.78 excluding GST
or four payments of $129.60
with
Learn More
each
A0419
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0124325018Associated Numbers
0124325018 0124325049 028903029A 028903029D 028903029S 028903029SX 028903029T 063533250180 063533250490 0986044850 11.1540 11210N 11210R 112396 20101052BN 20101052OE 2010250 2542239 2542239B 2542507 28-3724 301540RI 4037 437340 56842 89212769 8EL012426-201 8EL737777-001 9044850 9212769 944390448500 AEA5218 ALT10748 CA1540IR CAL10250AS CAL10250GS DRB4850 LRA01865 SG9B017 SG9B042 UD11337ASpecifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.9 Diesel | [AFF] | 03.1996-09.2001 |
| AUDI | A4 1.9 Diesel | [AFF] | 12.1995-11.2000 |
| AUDI | A4 1.9 TDi | [1Z] | 11.1994-07.1996 |
| AUDI | A4 1.9 TDi | [AFN] | 02.1996-07.1999 |
| AUDI | A4 1.9 TDi | [AFN] | 02.1996-12.1998 |
| AUDI | A4 1.9 TDi | [AHU] | 08.1996-07.1998 |
| AUDI | A4 1.9 TDi | [AJM] | 01.1998-11.2000 |
| AUDI | A4 1.9 TDi | [AJM] | 08.1998-09.2001 |
| AUDI | A4 1.9 TDi | [AVG] | 08.1999-06.2000 |
| AUDI | A4 1.9 TDi Quattro | [AJM] | 03.2000-09.2001 |
| AUDI | A4 1.9 TDi Quattro | [AJM] | 03.2000-11.2000 |
| AUDI | A4 1.9 TDi Quattro | [ATJ] | 03.2000-09.2001 |
| AUDI | A4 1.9 TDi Quattro | [ATJ] | 03.2000-11.2000 |
| AUDI | A4 1.9 TDi Quattro | [AVG] | 08.1999-01.2000 |
| AUDI | A6 1.9 TDi | [AFN] | 02.1998-04.2001 |
| AUDI | A6 1.9 TDi | [AFN] | 04.1997-04.2001 |
| AUDI | A6 1.9 TDi | [AJM] | 07.2000-01.2005 |
| VW | Passat 1.9 TDi | [AFN] | 06.1997-11.2000 |
| VW | Passat 1.9 TDi | [AFN] | 10.1996-11.2000 |
| VW | Passat 1.9 TDi | [AHH] | 06.1997-11.2000 |
| VW | Passat 1.9 TDi | [AHH] | 10.1996-11.2000 |
| VW | Passat 1.9 TDi | [AHU] | 06.1997-11.2000 |
| VW | Passat 1.9 TDi | [AHU] | 10.1996-11.2000 |
| VW | Passat 1.9 TDi | [AJM] | 08.1998-11.2000 |
| VW | Passat 1.9 TDi | [ATJ] | 08.1998-11.2000 |
| VW | Passat 1.9 TDi | [AVB] | 02.2000-11.2000 |
| VW | Passat 1.9 TDi | [AVB] | 11.2000-05.2005 |
| VW | Passat 1.9 TDi | [AVF] | 11.2000-05.2005 |
| VW | Passat 1.9 TDi | [AVG] | 06.1997-11.2000 |
| VW | Passat 1.9 TDi | [AWX] | 11.2000-05.2005 |
| VW | Passat 1.9 TDi Syncro 4-Motion | [AFN] | 06.1997-11.2000 |
| VW | Passat 1.9 TDi Syncro 4-Motion | [AFN] | 10.1996-11.2000 |
| VW | Passat 1.9 TDi Syncro 4-Motion | [ATJ] | 08.1999-11.2000 |
| VW | Passat 1.9 TDi Syncro 4-Motion | [AVG] | 08.1999-11.2000 |
| VW | Passat 1.9 TDi Syncro 4-Motion | [AVG] | 10.1996-11.2000 |
| VW | Passat 2.0 TDi | [BGW] | 12.2003-05.2005 |
Reference Information
| 0124325018 | BOSCH |
| 0124325049 | BOSCH |
| 028903029A | VW |
| 028903029D | VW |
| 028903029S | VW |
| 028903029SX | VW |
| 028903029T | VW |
| 028903029TX | VW |
| 063533250180 | MAGNETI MARELLI |
| 063533250490 | MAGNETI MARELLI |
| 074903018PX | VW |
| 0986044850 | BOSCH |
| 11.1540 | LAUBER |
| 11210N | WAI / TRANSPO |
| 11210R | WAI / TRANSPO |
| 112396 | CARGO |
| 20101052BN | REAL |
| 20101052OE | REAL |
| 2010250 | SANDO |
| 210183 | ERA |
| 2542239 | VALEO |
| 2542239B | VALEO |
| 2542507 | VALEO |
| 28-3724 | ELSTOCK |
| 28903029A | VW |
| 28903029D | VW |
| 28903029S | VW |
| 28903029SX | VW |
| 28903029T | VW |
| 28903029TX | VW |
| 301540RI | KUHNER |
| 4037 | CEVAM |
| 437340 | VALEO |
| 441687 | LOGISTIK |
| 56842 | EAI |
| 89212769 | POWERMAX |
| 8EL012426-201 | HELLA |
| 8EL737777-001 | HELLA |
| 9044850 | FRIESEN |
| 9212769 | POWERMAX |
| 944390448500 | MAGNETI MARELLI |
| AEA5218 | AUTOELECTRO |
| ALT00473 | ELECTROLOG |
| ALT10748 | WOODAUTO |
| ALT122500 | SIOM |
| ALT1867 | ELECTROLOG |
| ALT464CP | ROLLCO |
| ALTS762 | 3EFFE |
| CA1540IR | HC PARTS |
| CAL10250AS | CASCO |
| CAL10250GS | CASCO |
| DRB4850 | DELCO |
| F032112396 | CARGO |
| LRA01865 | LUCAS |
| LRA1865 | LUCAS |
| PRAS762 | 3EFFE |
| SG9B017 | VALEO |
| SG9B042 | VALEO |
| STA0460R | BOVEZ |
| STX100248 | STARDAX |
| STX100248R | STARDAX |
| UD11337A | AS-PL |
