Associated Numbers
0125711002 0125711047 0125711079 0986082610 11165 2010477 28-6681 31285627 36001105 36001105-0 554183RI AEK3571 CAL10477 CAL10477AS CAL10477ES CAL10477GS CAL10477OS CAL10477RS LRA03571 UD12545A UD12997A UNIT BOM 220-623Specifications
Amp | 150 A |
Diameter (D.1) | 10 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 5 qty |
Length (L.1) | 192 mm |
Mount Inside Length or Pad Mount C-C (C) | 90 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 54 mm |
Pad mount thickness (E.1) | 32 mm |
Pad mount thickness (E.2) | 32 mm |
Plug Code | PL_2305 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 60 mm |
Pulley Type | CLUTCH |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | S60 2.0 D3 | [D5204T2] | 01.2010-12.2011 |
VOLVO | S60 2.0 D3 | [D5204T7] | 01.2012- |
VOLVO | S60 2.0 D4 | [D5204T3] | 01.2011- |
VOLVO | S60 2.4 D5 | [D5244T10] | 01.2010-12.2011 |
VOLVO | S60 2.4 D5 | [D5244T11] | 01.2011- |
VOLVO | S60 2.4 D5 | [D5244T15] | 01.2011- |
VOLVO | S60 2.4 D5 AWD | [D5244T10] | 01.2010-12.2011 |
VOLVO | S60 2.4 D5 AWD | [D5244T11] | 01.2011- |
VOLVO | S60 2.4 D5 AWD | [D5244T15] | 01.2011- |
VOLVO | S80 2.4 D5 AWD | [D5244T10] | 01.2010- |
VOLVO | V60 2.0 D3 | [D5204T2] | 01.2010-12.2011 |
VOLVO | V60 2.0 D3 | [D5204T7] | 01.2012- |
VOLVO | V60 2.0 D4 | [D5204T3] | 01.2011- |
VOLVO | V60 2.0 T5 | [B5204T9] | 01.2014- |
VOLVO | V60 2.4 D4 AWD | [D5244T12] | 01.2013- |
VOLVO | V60 2.4 D4 AWD | [D5244T17] | 01.2012- |
VOLVO | V60 2.4 D5 | [D5244T10] | 01.2010- |
VOLVO | V60 2.4 D5 | [D5244T11] | 01.2010- |
VOLVO | V60 2.4 D5 | [D5244T15] | 01.2010- |
VOLVO | V60 2.4 D5 | [D5244T23] | 01.2010- |
VOLVO | V60 2.4 D5 AWD | [D5244T10] | 01.2010- |
VOLVO | V60 2.4 D5 AWD | [D5244T11] | 01.2010- |
VOLVO | V60 2.4 D5 AWD | [D5244T15] | 01.2010- |
VOLVO | V60 2.4 D5 AWD | [D5244T23] | 01.2010- |
VOLVO | V70 2.0 D3 | [D5204T2] | 01.2010-12.2011 |
VOLVO | V70 2.0 D3 | [D5204T7] | 01.2012- |
VOLVO | V70 2.4 D | [D5244T14] | 01.2009-12.2010 |
VOLVO | V70 2.4 D | [D5244T5] | 01.2007-12.2009 |
VOLVO | V70 2.4 D5 | [D5244T10] | 01.2009-12.2010 |
VOLVO | V70 2.4 D5 | [D5244T11] | 01.2011- |
VOLVO | V70 2.4 D5 | [D5244T15] | 01.2011- |
VOLVO | V70 2.4 D5 | [D5244T4] | 01.2007-12.2009 |
VOLVO | V70 2.4 D5 AWD | [D5244T10] | 01.2009-12.2011 |
VOLVO | V70 2.4 D5 AWD | [D5244T15] | 01.2011- |
VOLVO | V70 2.4 D5 AWD | [D5244T4] | 01.2007-12.2009 |
VOLVO | XC60 2.0 D3 | [D5204T7] | 01.2012- |
VOLVO | XC60 2.0 D3 DRIVEe | [D5204T2] | 01.2010-12.2012 |
VOLVO | XC60 2.0 D3 DRIVEe | [D5204T3] | 01.2010-12.2012 |
VOLVO | XC60 2.0 D4 | [B5204T3] | 01.2012- |
VOLVO | XC60 2.4 D4 AWD | [D5244T12] | 01.2011- |
VOLVO | XC60 2.4 D4 AWD | [D5244T17] | 01.2011- |
VOLVO | XC60 2.4 D5 AWD | [D5244T10] | 01.2009- |
VOLVO | XC60 2.4 D5 AWD | [D5244T23] | 01.2009- |
VOLVO | XC60 2.4 D5 AWD | [D5244T4] | 01.2009- |
VOLVO | XC60 2.4 D AWD | [D5244T16] | 01.2009-12.2011 |
VOLVO | XC60 2.4 D AWD | [D5244T5] | 01.2009-12.2011 |
VOLVO | XC60 2.4 D DRIVe | [D5244T14] | 01.2009-12.2010 |
Reference Information
LRA3571 441868 986082610 24142N CAL10477RS 125711002 ALTE045B AEK3571 ALT1653 36012618 125711047 ALTE045RR 36001105 0125711002 11165 UD12545A 220-623 0986082610 554183RI UD12997A AI-90211 BOM 31419555 360001105 UNIT 31285627 0125711047 CAL10477OS 125711079 A0487 LRA03571 36001105-0 ALTE045 CAL10477GS CGB-86681 ALT2172CP CAL10477ES 0125711079 28-6681 CAL10477 CAL10477AS 2010477 210852Video/Publications
0125711002 0125711047 0125711079 0986082610 11165 2010477 28-6681 31285627 36001105 36001105-0 554183RI A0487 AEK3571 AI-90211 ALTE045 ALTE045B ALTE045RR CAL10477 CAL10477AS CAL10477ES CAL10477GS CAL10477OS CAL10477RS CGB-86681 LRA03571 LRA3571 UD12545A UD12997A UNIT BOM 220-623 210852Add Your Number
