Associated Numbers
0124615021 11360N 115763 28-5770 305.525.150.010 553795RI 89215743 AEC1678 ALT10700 DRA0753 LRA03158 UD12226ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 5 qty |
| Length (L.1) | 199 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61.2 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30.5 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.9 TDi | [AVB] | 01.2001-12.2003 |
| AUDI | A4 1.9 TDi | [AVF] | 01.2001-12.2003 |
| AUDI | A4 1.9 TDi | [AWX] | 01.2000-12.2003 |
| AUDI | A4 1.9 TDi | [BKE] | 01.2004-12.2005 |
| AUDI | A4 1.9 TDi Quattro | [AVF] | 01.2001-12.2003 |
Reference Information
124615021 89215743 11360N 553795RI PRAS484 305.525.150.010 DRA0753 028903029N ALT10700 LRA03158 ALTS484 LRA3158 0124615021 115763 28-5770 ALTS484RR 028903029NX UD12226A AEC1678Video/Publications
0124615021 11360N 115763 28-5770 305.525.150.010 553795RI 89215743 AEC1678 ALT10700 ALTS484 ALTS484RR DRA0753 LRA03158 LRA3158 PRAS484 UD12226AAdd Your Number
