Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 644.16 including GST
NZ$ 560.14 excluding GST
or four payments of $161.04
with
Learn More
each
A1040
A0523
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
0124425084Associated Numbers
0124425084 1202197 13284408 135.583.100 209380 28-6679 4213 553982RI ALB5048UX ALB5084 ALB5084AN BOS0124425084 DRA0776 EAA-223116 LRA03569 UD12099A 20328RSpecifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 33.50 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 53.50 mm |
| Pulley to Mount Distance (A) | 54 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Meriva B 1.4 | [A14NEL] | 06.2010- |
| OPEL | Meriva B 1.4 | [A14NET] | 06.2010- |
| OPEL | Meriva B 1.4 | [A14XER] | 06.2010- |
| OPEL | Meriva B 1.4 | [B14NEL] | 06.2010- |
| OPEL | Meriva B 1.4 | [B14NET] | 06.2010- |
| OPEL | Meriva B 1.4 | [B14XER] | 06.2010- |
| OPEL | Meriva B 1.4 LPG | [A14NEL] | 06.2011- |
| OPEL | Meriva B 1.4 LPG | [B14NEL] | 06.2011- |
| VAUXHALL | Meriva B 1.4 | [A14NEL] | 01.2010- |
| VAUXHALL | Meriva B 1.4 | [A14NET] | 01.2010- |
| VAUXHALL | Meriva B 1.4 | [A14XER] | 01.2010- |
Reference Information
| 0124425084 | BOSCH |
| 1202197 | OPEL |
| 1202326 | OPEL |
| 13214408 | GM |
| 13284408 | OPEL |
| 135.583.100 | PSH |
| 20328R | WAI / TRANSPO |
| 209380 | ERA |
| 28-6679 | ELSTOCK |
| 4213 | CEVAM |
| 441867 | LOGISTIK |
| 553982RI | KUHNER |
| 95515956 | GM |
| 95515956 | VAUXHALL |
| 95515956 | OPEL |
| ALB5048UX | KRAUF |
| ALB5084 | KRAUF |
| ALB5084AN | KRAUF |
| ALT1418 | ELECTROLOG |
| ALTE209 | 3EFFE |
| BOS0124425084 | WOODAUTO |
| DRA0776 | DELCO |
| LRA03569 | LUCAS |
| LRA3569 | LUCAS |
| PRAE209 | 3EFFE |
| REG121350 | SIOM |
| REG121350A | SIOM |
| UD12099A | AS-PL |
Video/Publications
A0523Related Items
View your shopping basket or Browse other items in Alternators.
