Associated Numbers
0125711035 0125711082 0125711089 0125711125 0125711126 0125711149 059903018S 059903018SX 059903019J 059903019JX 059903019M 059903019MX 059903019N 059903019NX 2010540 28-7563 40006 554281RIV 57420 A0575S AEK3953 ALB9801 ALT10763 BOS0125711149 CAL10540 CAL10540AS CAL10540ES CAL10540GS CAL10540OS CAL10540RS DA2218 DRA1108 EAA-223202 LRA03953 LRA3953 UD13503A UNIT BOM 220-010Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 13.5 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 182 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 3.0 TDi | [CLAB] | 01.2011- |
| AUDI | A4 3.0 TDi Quattro | [CDUC] | 01.2011- |
| AUDI | A4 3.0 TDi Quattro | [CKVB] | 01.2011- |
| AUDI | A4 3.0 TDi Quattro | [CKVC] | 01.2011- |
| AUDI | A5 3.0 TDi | [CLAB] | 01.2011- |
| AUDI | A5 3.0 TDi Quattro | [CDUC] | 01.2011- |
| AUDI | A5 3.0 TDi Quattro | [CKVB] | 01.2011- |
| AUDI | A5 3.0 TDi Quattro | [CKVC] | 01.2011- |
| AUDI | Q5 3.0 TDi Quattro | [CDUD] | 01.2012- |
| AUDI | Q5 3.0 TDi Quattro | [CGQB] | 01.2012- |
| AUDI | Q5 3.0 TDi Quattro | [CTBA] | 01.2012- |
| AUDI | Q5 3.0 TDi Quattro | [CTBC] | 01.2012- |
| AUDI | Q5 3.0 TDi Quattro | [CVUB] | 01.2015- |
| AUDI | Q5 3.0 TDi Quattro | [CVUC] | 01.2012- |
| AUDI | Q5 3.0 TDi Quattro | [DEHA] | 01.2015- |
Reference Information
205.553.150.014 20101045BN 205.553.150.210 554281RIV 125711082 125711089 LRA3953 125711126 0125711082 125711125 57420 CGB-87563 20101045OE 059903019NX 0125711089 059903019JX 5510637 CAL10540GS 059903018S BOM UNIT 2010540.1 0125711149 12090738 LRA03953 A12BH0752AS 125711150 125711035 ALB9801 059903018SX 059903019MX 0125711035 059903019M 059903019N ALTF138 89215782 059903019J 0125711150 A0575S AEK3953 40006 UD13503A BOS0125711149 DA2218 125711149 A12BH0752 ALT10339 28-7563 ALT125400A CAL10540AS DRA1108 PRAF138 2010540 0125711126 0125711125 32711149 ALT10763 220-010 ALT125400 EAA-223202 11730NVideo/Publications
0125711035 0125711082 0125711089 0125711125 0125711126 0125711149 059903018S 059903018SX 059903019J 059903019JX 059903019M 059903019MX 059903019N 059903019NX 12090738 2010540 28-7563 32711149 40006 554281RIV 57420 A0575S AEK3953 ALB9801 ALT10763 ALT125400 ALT125400A ALTF138 BOS0125711149 CAL10540 CAL10540AS CAL10540ES CAL10540GS CAL10540OS CAL10540RS CGB-87563 DA2218 DRA1108 EAA-223202 LRA03953 LRA3953 PRAF138 UD13503A UNIT BOM 220-010Add Your Number
