Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 464.08 including GST
NZ$ 403.55 excluding GST
or four payments of $116.02
with
Learn More
each
A0683S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0123510028Associated Numbers
0123510028 0123515012 046903015F 046903015FX 113758 13623R 2010219 20130239 205.506.120.010 205.506.120.210 28-2813 301141RI 301141RIR 4517 89212772 8EL011712-171 8EL737161-001 9039690 944390396900 AEC1141 CA1141IR CAL10219 CAL10219AS CAL10219ES CAL10219GS CAL10219OS CAL10219RS DRA3966 EAA-241350-R LRA01634 MG57 UD15490ASpecifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | M10x1.5 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 181 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.50 mm |
| OEM Product | No |
| Plug Code | PL_9106 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 64.50 mm |
| Pulley to Mount Distance (A) | 31.50 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | 100 2.2 Quattro | [ANN] | 01.1993-12.1994 |
| AUDI | 100 2.5 TDi | [AAT] | 01.1991-12.1994 |
| AUDI | 100 2.5 TDi | [ABP] | 01.1991-12.1994 |
| AUDI | A6 2.3 | [AAR] | 01.1994-12.1997 |
| AUDI | A6 2.3 Quattro | [AAR] | 01.1994-12.1997 |
| AUDI | A6 2.5 TDi | [AAT] | 01.1994-12.1997 |
| AUDI | A6 2.5 TDi | [AEL] | 01.1994-12.1997 |
| AUDI | Passat 2.5 TDi | [AFB] | 01.1998-12.2000 |
| AUDI | Passat 2.5 TDi | [AKN] | 01.1998-12.2000 |
| AUDI | S6 2.2 Quattro | [AAN] | 01.1994-12.1997 |
Reference Information
| 0123510028 | BOSCH |
| 0123515012 | BOSCH |
| 046903015 | VW |
| 046903015F | VW |
| 046903015FX | VW |
| 046903017 | VW |
| 046903017X | VW |
| 049903015F | VW |
| 049903015FX | VW |
| 059903015 | VW |
| 059903015X | VW |
| 113758 | CARGO |
| 13623R | WAI / TRANSPO |
| 2010219 | SANDO |
| 20130239 | PRESTOLITE |
| 205.506.120.010 | PSH |
| 205.506.120.210 | PSH |
| 210202 | ERA |
| 28-2813 | ELSTOCK |
| 301141RI | KUHNER |
| 301141RIR | KUHNER |
| 310652 | RHIAG |
| 441288 | LOGISTIK |
| 4517 | CEVAM |
| 59903015 | VW |
| 59903015X | VW |
| 89212772 | POWERMAX |
| 8EL011712-171 | HELLA |
| 8EL737161-001 | HELLA |
| 9039690 | FRIESEN |
| 944390396900 | MAGNETI MARELLI |
| A12BH0735A2 | SIDAT |
| AEC1141 | AUTOELECTRO |
| ALT122190 | SIOM |
| ALT1843 | ELECTROLOG |
| ALT6720 | SIOM |
| ALTS589 | 3EFFE |
| ALTS589B | 3EFFE |
| ALTS589L | 3EFFE |
| ANM36186X | ANDEL |
| CA1141IR | HC PARTS |
| CAL10219 | CASCO |
| CAL10219AS | CASCO |
| CAL10219ES | CASCO |
| CAL10219GS | CASCO |
| CAL10219OS | CASCO |
| CAL10219RS | CASCO |
| CGB-82813 | AINDE |
| DRA3966 | DELCO |
| F032113758 | CARGO |
| LRA01634 | LUCAS |
| LRA1634 | LUCAS |
| MG57 | MAHLE |
| PRAS589 | 3EFFE |
| STX100197 | STARDAX |
| STX100197R | STARDAX |
| STX100854 | STARDAX |
| STX100903 | STARDAX |
| STX101379 | STARDAX |
| STX101379R | STARDAX |
| UD15490A | AS-PL |
| UD17085A | AS-PL |
Video/Publications
