Remanufactured AS-PL Alternator
PREMIUM LINE
AS-PL
BOSCH
Price:
NZ$ 411.03 including GST
NZ$ 357.42 excluding GST
or four payments of $102.76
with
Learn More
each
A0686PR
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Associated Numbers
0120468121 0123510015 034903016N 13817R 28-6584 301140RI 305.520.120 4593 89213134 8EL737160-001 943355045010 944390412000 ALB1140 CA1140IR LRA03474 MAR5545 MRA41200Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | M10x1.5 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 69 mm |
| Pulley to Mount Distance (A) | 33.50 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | RS2 2.2 Quattro | [ADU] | 03.1994-05.1995 |
| AUDI | S2 2.2 Quattro | [ABY] | 02.1993-07.1995 |
| AUDI | S2 2.2 Quattro | [ABY] | 02.1993-12.1994 |
| AUDI | S2 2.2 Quattro | [ABY] | 10.1992-12.1996 |
Reference Information
| 0120468121 | BOSCH |
| 0123510015 | BOSCH |
| 034903016N | VW |
| 13817R | WAI / TRANSPO |
| 28-6584 | ELSTOCK |
| 301140RI | KUHNER |
| 305.520.120 | PSH |
| 305.520.120.460 | PSH |
| 310651 | RHIAG |
| 4593 | CEVAM |
| 89213134 | POWERMAX |
| 8EL737160-001 | HELLA |
| 943355045010 | MAGNETI MARELLI |
| 944390412000 | MAGNETI MARELLI |
| ALB1140 | KRAUF |
| ALT1237 | ELECTROLOG |
| ALTW268 | 3EFFE |
| CA1140IR | HC PARTS |
| LRA03474 | LUCAS |
| LRA3474 | LUCAS |
| MAR5545 | MAGNETI MARELLI |
| MRA41200 | MAGNETI MARELLI |
| PRAW268 | 3EFFE |
| STX101378 | STARDAX |
Video/Publications
A0686PRView your shopping basket or Browse other items in Alternators.
