Information
0124525007Associated Numbers
0124525007 13917N 160-55103 89214008 90-15-6448 A-6421 ALB3808 UD10069ASpecifications
Amp | 136 A |
Bottom Mounting Foot Width (B) | 12 mm |
Diameter (D.1) | 11.50 mm |
Diameter (D.2) | 10.50 mm |
Diameter (D.3) | 10.50 mm |
Length (L.1) | 181 mm |
Mount Inside Length or Pad Mount C-C (C) | 53.50 mm |
OEM Product | No |
Plug Code | PL_2802 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 7 qty |
Pulley Outside Diameter (O.D.1) | 59 mm |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | Solid |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Ram 2500 8.0 | 01.2002-12.2003 | |
DODGE | Ram 3500 8.0 | 01.2002-12.2003 |
Reference Information
0124525007 | BOSCH |
13917N | WAI / TRANSPO |
160-55103 | DIXIE |
89214008 | POWERMAX |
90-15-6448 | WILSON |
A-6421 | DIXIE |
ALB3808 | KRAUF |
UD10069A | AS-PL |
Video/Publications
