Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 498.30 including GST
NZ$ 433.30 excluding GST
or four payments of $124.58
with
Learn More
each
A0698S
2
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
0124355001Associated Numbers
0124355001 21K0-18-2610 220-30123 546.502.050 554989RI 554989RIB 75261184 90-15-6646 A-6674 ALB5554 BOS0124355001 UD20707A UNIT BOM 220-5741Specifications
| Amp | 50 A |
| Bottom Mounting Foot Width (B) | 76 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | M10x1.5 mm |
| Length (L.1) | 203.50 mm |
| OEM Product | No |
| Plug Code | PL_5003 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 100 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 845 | [6BTA] | 01.2002-12.2007 |
| CASE | 845 | [6BTA] | 01.2008-12.2010 |
| CASE | 865 | [6BTA] | 01.2002-12.2007 |
| CASE | 865 5.9 DHP | [QSB] | 01.2005-12.2006 |
| CASE | 885 | [6CT] | 01.2007-12.2010 |
| CASE | 885 | [6CT] | 01.2008-12.2010 |
| CASE | 885 AWD | [6CT] | 01.2008-12.2010 |
| KOMATSU | GD523A 5.9 | [6BT] | 01.2003-12.2005 |
| KOMATSU | GD623A | [6CT] | 01.2003-12.2005 |
| KOMATSU | GD623R 5.9 | [6BT] | 01.2003-12.2005 |
| KOMATSU | WA180 5.9 | [6BT] | 01.2003-12.2005 |
| NEW HOLLAND | G140 6.7 | [QSB] | 01.2006-12.2015 |
| NEW HOLLAND | G170 6.7 | [QSB] | 01.2006-12.2015 |
| NEW HOLLAND | RG170B 5.9 | [QSB] | 01.2005-12.2015 |
Reference Information
| 0124355001 | BOSCH |
| 21K0-18-2610 | KOMATSU |
| 220-30123 | ROBERT'S |
| 546.502.050 | PSH |
| 546.502.050.014 | PSH |
| 554989RI | KUHNER |
| 554989RIB | KUHNER |
| 5610093 | MEAT & DORIA |
| 75261184 | CASE |
| 90-15-6646 | WILSON |
| A24BH0135A2 | SIDAT |
| A24BH0135AS | SIDAT |
| A-6674 | DIXIE |
| ALB5554 | KRAUF |
| ALTJ155 | 3EFFE |
| BOS0124355001 | WOODAUTO |
| UD20707A | AS-PL |
| UNIT BOM 220-5741 | WAI / TRANSPO |
Video/Publications
A0698SRelated Items
