Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 292.23 including GST
NZ$ 254.11 excluding GST
or four payments of $73.06
with
Learn More
each
A1009
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
3493273Associated Numbers
0124415010 0986043990 10480273 11.1473 112720 1204054 20101893RC 2010398 2012115 20133511BN 21952R 273 28-2910 28-3954 301473RI 3472273 3493273 35215015 35215225 437464 56885 6204074 8EL012426-721 8EL737685-001 9090130 9119309 9132653 9213538 922 AEA4206 ALT10291 CA1473IR CAL10398GS CAL10398RS CAL12115AS DRA3904 DRA3904N EAA-221193 IA9424 LRA01685 LRB00406 SA200 21952NSpecifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 33.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 175 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 36 mm |
| Pulley Outside Diameter (O.D.2) | 62 mm |
| Pulley to Mount Distance (A) | 53 mm |
| Pulley Type | Solid |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra G 1.7 TD | [X17DTL] | 03.1998-08.2000 |
| VAUXHALL | Astra G 1.7 TD | [X17DTL] | 03.1998-08.2000 |
| VAUXHALL | Astravan MK IV 1.7 TD | [X17DTL] | 08.1998-08.2000 |
Reference Information
| 0124415010 | BOSCH |
| 0986043990 | BOSCH |
| 10457922 | VAUXHALL |
| 10457922 | GM |
| 10457922 | OPEL |
| 10480273 | DELCO |
| 11.1473 | LAUBER |
| 112720 | CARGO |
| 1204054 | OPEL |
| 20101893RC | REAL |
| 2010398 | SANDO |
| 2012115 | SANDO |
| 20133511BN | REAL |
| 210155 | ERA |
| 21952N | WAI / TRANSPO |
| 21952R | WAI / TRANSPO |
| 273 | DELCO |
| 28-2910 | ELSTOCK |
| 28-3954 | ELSTOCK |
| 301473RI | KUHNER |
| 310838 | RHIAG |
| 3472273 | DELCO |
| 3493273 | DELCO |
| 35215015 | PRESTOLITE |
| 35215225 | PRESTOLITE |
| 437464 | VALEO |
| 441620 | LOGISTIK |
| 56885 | EAI |
| 6204074 | OPEL |
| 6204114 | OPEL |
| 6204124 | OPEL |
| 6204153 | OPEL |
| 8EL012426-721 | HELLA |
| 8EL737685-001 | HELLA |
| 9090130 | FRIESEN |
| 9117852 | VAUXHALL |
| 9117852 | OPEL |
| 9119309 | OPEL |
| 9132653 | OPEL |
| 9213538 | POWERMAX |
| 922 | DELCO |
| 93175801 | VAUXHALL |
| 93175801 | OPEL |
| 93175817 | VAUXHALL |
| 93175947 | OPEL |
| 9512787 | VAUXHALL |
| 9512787 | OPEL |
| A1009 | AS-PL |
| A12DR0633A2 | SIDAT |
| AEA4206 | AUTOELECTRO |
| ALT10291 | WOODAUTO |
| ALT123980 | SIOM |
| ALT123980R | SIOM |
| ALT2316 | ELECTROLOG |
| ALT4850 | SIOM |
| ALTS004 | 3EFFE |
| ALTS004L | 3EFFE |
| ANM36124X | ANDEL |
| CA1473IR | HC PARTS |
| CAL10398GS | CASCO |
| CAL10398RS | CASCO |
| CAL12115AS | CASCO |
| DRA3904 | DELCO |
| DRA3904N | DELCO |
| F032112720 | CARGO |
| IA9424 | ISKRA / LETRIKA |
| LRA01685 | LUCAS |
| LRA1685 | LUCAS |
| LRB00406 | LUCAS |
| LRB406 | LUCAS |
| MG 447 | MAHLE |
| PRAS004 | 3EFFE |
| PRAS004L | 3EFFE |
| R1530039 | OPEL |
| R1530039 | VAUXHALL |
| SA200 | SOVEREIGN |
| STA0078R | BOVEZ |
| STX100152 | STARDAX |
| STX101443 | STARDAX |
Video/Publications
