Information
LR260502Associated Numbers
8971430110 LR260-502 MXA263 65-3013-1
Specifications
Amp | 60 A |
Bottom Mounting Foot Width (B) | 17 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.50 mm |
Diameter (D.3) | 10.50 mm |
Length (L.1) | 290 mm |
Mount Inside Length or Pad Mount C-C (C) | 79.50 mm |
OEM Product | No |
Plug Code | PL_4500 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 3 qty |
Pulley Groove Width (W.1) | 11.50 mm |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley Outside Diameter (O.D.2) | 82 mm |
Pulley to Mount Distance (A) | 40.50 mm |
Pulley Type | Solid |
Unit Type | HITACHI |
Vacuum Pump | Yes |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BOGDAN | A-091 4.6D | [4HE1, 4HG1] | 01.2000-12.2003 |
BOGDAN | A-091 4.6D | [4HE1,4HG1] | 01.2000-12.2003 |
Reference Information
20145716BN | REAL |
2020617.0 | SANDO |
446950 | LOGISTIK |
8971430110 | ISUZU |
8971753901 | ISUZU |
A2018 | AS-PL |
ALT226170A | SIOM |
CAL20617AS | CASCO |
LR260-502 | HITACHI |
