Associated Numbers
0986037831 11.0874 111235 1204007 1204008 1204084 1204144 20110154 20145811BN 2020118 22430N 28-1924 40874RI 437179 437881 56373 89213751 8943325811 8943325812 8EL732720-001 9037831 9353 94332581 ALT32176 CAL20118AS DRA3297 EAA-221829 JA874IR LR170-415 LR170-415B LR170-415C LRA01430Specifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 1 qty |
Groove Width (W.1) | 12.5 mm |
Length (L.1) | 215 mm |
Mount Inside Length or Pad Mount C-C (C) | 81 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 82 mm |
Plug Code | PL_4500 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Kadett E 1.5 TD | [15DT(T4EC1)] | 09.1988-08.1991 |
Reference Information
JA874IR VP705100 111235 1204084 8-94332-581 28-1924 56373 1204007 1204008 002-U904 20145811BN LR170-415 ALT3132 437179 89213751 9353 2020118 0986037831 20110154 22430N PRAF367 ALT5520 437881 11.0874 VP705000 CAL20118AS LRA1430 40874RI 1204144 LR170-415C 2U904 ALTF367 445923 LR170-415B 986037831 ALT5410 94332581 A2026 8943325812 8943325811 ALT32176 LRA01430 EAA-221829 VP705C00 9037831 DRA3297 ALU904 CGB-13296 8EL732720-001 ANM35517XVideo/Publications
002-U904 0986037831 11.0874 111235 1204007 1204008 1204084 1204144 20110154 20145811BN 2020118 22430N 28-1924 2U904 40874RI 437179 437881 56373 89213751 8943325811 8943325812 8EL732720-001 9037831 9353 ALT32176 ALT5410 ALT5520 ALTF367 ALU904 CAL20118AS CGB-13296 DRA3297 EAA-221829 JA874IR LR170-415 LR170-415B LR170-415C LRA01430 LRA1430 PRAF367Add Your Number
