Associated Numbers
0986032651 11.5104 110168 110330 14303N 20100348 2045100 28-0522 40101 40104RI 40105RI 40197RI 40884RI 436505 436506 436549 8EL726260-001 9051122 9148 9212467 AEA3148 CAL20171AS CAL45100 CAL45100AS CAL45100ES CAL45100GS CAL45100OS CAL45100RS DRA2441 DRA2621 DRA2651 DRA2681 DRA3471 DRA5161 DRA5411 JA104 JA104IR LR150-100 LR150-101 LR150-101B LR150-125 LR150-125B LR150-177 LR150-31 LR150-35 LR150-36 LR150-50 LR150-52 LR150-53 LR150-58 LR150-66 LR150-67 LR150-98 LR150-98B LR150-98E LR150-99 LR150-99B LRA01176 UD02255ASpecifications
| Amp | 50 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 12.5 mm |
| Length (L.1) | 174 mm |
| Mount Inside Length or Pad Mount C-C (C) | 80.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 44 mm |
| Outside Diameter (O.D.2) | 72 mm |
| Plug Code | PL_2807 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | 200SX 2.0 | [Z20E] | 01.1980-01.1981 |
| NISSAN | 200SX 2.2 | [Z22E] | 01.1982-01.1983 |
| NISSAN | 510 2.0 | [L20B] | 01.1978-01.1979 |
| NISSAN | 510 2.0 | [Z20S] | 01.1980-01.1981 |
| NISSAN | 720 2.0 | [Z20] | 01.1983-01.1985 |
| NISSAN | 720 2.2 | [Z22] | 01.1981-01.1982 |
| NISSAN | 720 2.2 | [Z22] | 01.1983- |
| NISSAN | 720 2.4 | [Z24] | 01.1983-01.1985 |
| NISSAN | Bluebird 1.8 | [L18S] | 01.1980-05.1984 |
| NISSAN | Bluebird 1.8 | [L18S] | 01.1980-12.1983 |
| NISSAN | Bluebird 1.8 | [L18T] | 01.1980-05.1984 |
| NISSAN | Bluebird 2.0 | [Z20E] | 01.1982-12.1983 |
| NISSAN | CheRy 1.0 | [A10S] | 08.1978-07.1981 |
| NISSAN | CheRy 1.0 | [E10] | 05.1982-05.1986 |
| NISSAN | CheRy 1.3 | [E13] | 05.1982-10.1986 |
| NISSAN | CheRy 1.3 | [E13] | 08.1981-09.1982 |
| NISSAN | CheRy 1.3 | [E13] | 09.1981-12.1983 |
| NISSAN | CheRy 1.4 | [A14S] | 08.1980-07.1981 |
| NISSAN | CheRy 1.5 | [E15] | 08.1981-12.1982 |
| NISSAN | CheRy 1.5 | [E15S] | 11.1983-10.1986 |
| NISSAN | King Cab 1.6 | [Z16] | 01.1989- |
| NISSAN | King Cab 2.0 | [Z20] | 01.1989- |
| NISSAN | King Cab 2.0 | [Z20] | 09.1985-02.1998 |
| NISSAN | King Cab 2.4 | [Z24] | 09.1985-04.1992 |
| NISSAN | King Van 2.0 | [Z20] | 11.1986-01.1995 |
| NISSAN | King Vanette 1.5 | [A15S] | 09.1986-07.1995 |
| NISSAN | King Vanette 2.0 | [Z20S] | 09.1986-04.1993 |
| NISSAN | Micra 1.0 | [MA10S] | 12.1982-05.1989 |
| NISSAN | Micra 1.0 | [MA10S] | 12.1982-12.1989 |
| NISSAN | Pick Up 1.8 | [L18] | 01.1983-03.1986 |
| NISSAN | Pick Up 2.0 | [Z20] | 09.1985-07.1988 |
| NISSAN | Pick Up 2.0 | [Z20] | 09.1988-08.1991 |
| NISSAN | Pick Up 2.2 4WD | [Z22] | 04.1983-03.1986 |
| NISSAN | Pick Up 2.4 4WD | [Z24] | 09.1985-04.1992 |
| NISSAN | Prairie 1.5 S | [E15S] | 01.1984-12.1987 |
| NISSAN | Sunny 1.3 | [E13] | 03.1982-09.1987 |
| NISSAN | Sunny 1.3 | [E13] | 04.1982-09.1986 |
| NISSAN | Sunny 1.3 | [E13] | 08.1982-08.1990 |
| NISSAN | Sunny 1.4 | [A14] | 01.1970-02.1982 |
| NISSAN | Sunny 1.5 | [A15] | 06.1979-02.1982 |
| NISSAN | Sunny 1.5 | [E15S] | 03.1982-10.1986 |
| NISSAN | Sunny 1.6 4WD | [E16i] | 06.1986-05.1989 |
| NISSAN | Urvan 2.0 | [H20] | 07.1981-11.1982 |
| NISSAN | Urvan 2.0 | [Z20] | 05.1987-05.1997 |
| NISSAN | Urvan 2.0 | [Z20] | 12.1982-11.1988 |
| NISSAN | Vanette 1.5 | [A15] | 01.1983-12.1987 |
| NISSAN | Vanette 1.5 | [A15S] | 10.1986-12.1995 |
Reference Information
23100H7710 LR150129 2310027G10RE LR15036A 23100H7711 2310027G00 A002T24272 23100U9502 23100U9503 B310M10B10EX LR150123 A005T20872 A005T20871 ALT221710 23100-W7111 23100-W7110 A5T00272 23100H7703 23100H7702 23100H7701 DRA3471 23100H7700 LR150-99 LR150-98 DRA5411 2310027G10 A005T06671 23100-10B10 CAL45100GS ALT221700 23100-W7101 23100-W7100 23100B17G2 AQ2060N7 23100-M6610 N221-18-300 2310005B10 0986032651 23100-W6811 2T371 ALM368 LR150-98B LR150-98E A002T24371 A2T24072 AQ2250D32 A002T24372 23100B9810 A002T21782 A002T22871 CAL45100ES A002T40971 23100P2504 LR150-177 23100P2507 A002T17172 23100P2505 23100P2506 23100B9805 23100B9800 23100B9801 A005T21879 23100B9802 23100-M6601 23100-M6600 23100M6601EP A005T21871 ALD332 LR150-125 002-D335 40104RI ALD335 002-D332 ANM37631X DRA5161 23100H7701EP 23100-B9810 ALT3013 A2065 A5T20374 A2T22272 ALTL403 210105 2D332 AEA3148 23100W5801 2310010B10 2D335 23100W5802 23100W5803 14303N LRA01176 ALT221470 A3T33272 23100-U9503 23100-U9502 23100-U9501 23100-U9500 23100N9512EP 40884RI PRAL341 23100-27G10RE A2T22282 23100W5811 23100W5810 40105RI 23100W5815 110168 23100-M5960 002-M368 23100N9502 A002T22272 23100N9500 23100U9502L 210124 2310001N13 A005T20972 23100-W7015 11.5104 A5T06671 23100-05B10 DRA2681 A002T22282 DRA2441 23100-B9800 23100N9510 23100-B9801 23100-B9802 23100N9512 23100N9511 23100-B9805 23100-B17G2 23100A4M10 23100M6600 23100M6601 40101 445153 LRA1176 23100-01B10 311771 DRA2651 A5T20972 23100-Q4511 23100-W5811RE A2T22871 A2T24371 A2T21782 A2T24372 2M368 429907050 23100W6811 A2T17172 436549 N221-18-300C CGB-12651 23100-27G10 23100W7101 UD02255A LR15030 CAL45100OS 23100-Q4501 23100-R2003 A2T40971 28-0522 LR15039 23100-10W01 LR150-101B LR150-125B 23100W5811RE JA104IR LR150-101 LR150-100 AQ2050N12 LR15030B 23100-27G00 23100-U9510 23100-U9513 23100-U9512 23100-U9511 A5T20871 A5T20872 1516878R 23100-W5807L A005T20374 20100348 23100-W5807R 23100M5961 002-T371 A005T00272 ALT371 23100M5960 JA104 23100H7205 LR150-31 9051122 23100-N9511 23100-N9510 23100-N9512 2310004M10 23100R9011 LR150-36 LR150-35 23100-N9512-EP 9148 2045100 23100-H7700 23100-H7703 23100-H7702 23100-H7701 23100W7015 LR150-66 A2T24172 23100-N9500 23100-W5816 LR16035 23100-N9502 23700AA040 23100-W5815 23100Q4511 LR16039 A2T24971 A2T24972 AQ2050A24 A002T24072 2310004M00 LR150-67 436506 N221-18-300XA 110330 436505 AQ2250C2 23100-W5810 23100-W5811 LR150-53 23100-W5807 LR150-52 ALT471000 23100-W5805 23100H7702L LR150-50 1516835R 23100-W5806 DRA2621 LR150-99B A5T21871 23100-W5803 23100Q4501 23100Q4500 A005T21897 LR150-58 A2T21474 A5T21879 8EL726260-001 ALTL341 986032651 23100-W5801 23100-W5802 23100-W5800 LR15085 CAL45100RS 2310001B10 A002T24971 A002T24972 A2T24272 23100-04M00 A002T24172 23100M6610 9212467 CAL45100AS 23100-H7711 23100-H7710 CAL45100 23100U9510 A5T21897 23100U9512 40197RI 23100U9513 A002T21474 23100-04M10 PRAL403 23100-R9011Video/Publications
002-D332 002-D335 002-M368 002-T371 0986032651 11.5104 110168 110330 14303N 20100348 2045100 28-0522 2D332 2D335 2M368 2T371 311771 40101 40104RI 40105RI 40197RI 40884RI 436505 436506 436549 8EL726260-001 9051122 9148 9212467 AEA3148 ALD332 ALD335 ALM368 ALT221470 ALT221700 ALT221710 ALT371 ALT471000 ALTL341 ALTL403 CAL45100 CAL45100AS CAL45100ES CAL45100GS CAL45100OS CAL45100RS CGB-12651 DRA2441 DRA2621 DRA2651 DRA2681 DRA3471 DRA5161 DRA5411 JA104 JA104IR LR150-100 LR150-101 LR150-101B LR150-125 LR150-125B LR150-177 LR150-31 LR150-35 LR150-36 LR150-50 LR150-52 LR150-53 LR150-58 LR150-66 LR150-67 LR150-98 LR150-98B LR150-98E LR150-99 LR150-99B LRA01176 LRA1176 PRAL341 PRAL403 UD02255A 210105 210124Add Your Number
