Information
LR280-708BAssociated Numbers
2020611 553745RI 8980298921 ALH4921 ALH7921 ALH8921 ALT32234 HITLR280-708 LR280-708 LR280-708B LR280-708C UD13545A
HXA064 ANJ415 65-3016-2 65-3016-2G
Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 17.50 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | M10x1.5 mm |
Length (L.1) | 225 mm |
Mount Inside Length or Pad Mount C-C (C) | 76 mm |
OEM Product | No |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 7 qty |
Pulley Outside Diameter (O.D.1) | 65 mm |
Pulley to Mount Distance (A) | 59 mm |
Pulley Type | Solid |
Unit Type | HITACHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | NLR 85 | [4HK1] | |
ISUZU | NPR 75 | [4JJ1] |
Reference Information
136.009.080.080 | PSH |
136.009.080.088 | PSH |
136.009.080.089 | PSH |
136154 | HITACHI |
2506154 | HITACHI |
553745RI | KUHNER |
553745RIH | KUHNER |
553745RIM | KUHNER |
8980298921 | ISUZU |
8980298922 | ISUZU |
A2079S | AS-PL |
A24HT0018A2 | SIDAT |
ALH4921 | KRAUF |
ALH7921 | KRAUF |
ALH8921 | KRAUF |
ALT226110 | SIOM |
ALT226110A | SIOM |
CGB-10708 | AINDE |
HITLR280-708 | WOODAUTO |
LR280-708 | HITACHI |
LR280-708B | HITACHI |
LR280-708C | HITACHI |
UD13545A | AS-PL |
Video/Publications
A2079SRelated Items
